REV I | 8/6/19
15
8. Safety Ratchet Retrot Kit
8.1 Installation
WARNING:NOpersons,otherthanqualiedpersonnel,shouldmaintainorservicethissystem.
WARNING: Before performing maintenance on this system, ensure that all energy sources are properly
isolated as described in the Safety–Energy Isolation section.
Components diagrams are located on the next page.
1. Ensure bucket (I) is empty and fully lowered.
2. Turnoandisolateenergysources,andperformin-houselock-out/tag-outprocedure.
3. Unbolt hand valve (A) from bucket (I).
4. Remove bucket pivot pin (K) from frame pivot tubes (B) and bucket pivot tube (J).
NOTE: Remove retaining bolts to allow removal of pivot pin.
5. Disconnect safety chain (H) from frame (D).
6. Remove airbag pivot pin (F) from airbag bracket (E). NOTE: Remove cotter pin from either end
of airbag pivot pin to allow removal.
7. Move bucket (I) away from frame (D) then orient bucket to allow access to rear corner (Figure 5).
8. Mount ratchet assembly (M, N, O) as follows:
a. Locate ratchet assembly (M, N, O) on the outer rear corner of the bucket (I) as shown in
Figure 5.
b. Trace the (8) holes on the ratchet bracket (M) onto the bucket (I).
c. Center punch holes traced in previous step.
d. With 21/64" drill bit, drill clearance holes into pilot holes.
e. Using 5/16" bolts and 5/16" locknuts, fasten the ratchet assembly (M, N, O) in place.
9. Mount ratchet gear (P) as follows:
a. Facing inside of frame (D), locate ratchet gear (P) on holes in frame—location (Q). The
ratchet gear should be oriented teeth down.
b. Install5/16"bolts,lockwashers,andatwashers(inorderlisted),liftratchetgear(P)ashigh
as high as possible, then loosely fasten gear ratchet in place. NOTE: Permanent tightening
willtakeplaceafternaladjustment.
10. Re-connect bucket (I) to frame (D) as follows:
a. Move the bucket (I) into the inside of frame (D), and align bucket airbag pivot (L) with holes
in airbag bracket (E). Insert airbag pivot pin (F) and insert cotter pins through pivot pins.
b. Re-connect safety chain (H).
c. Insert bucket pivot pin (K) through frame and bucket pivot tubes (B), (J); then install retaining
bolt at each end of bucket pivot pin. NOTE: Pivot pins can be lubricated at this time.
d. Fasten hand valve (A) in original location on bucket.
Procedure continues after Component Diagrams page (next).
