TABLE OF CONTENTS Rev. 5/23/2025 AHS MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Corp. Page 21 of 26
Step 3: Tighten the beam clamp fasteners to 50 - 52 ft·lb of torque.
Step 4: Stand the crane on its feet.
Rotate the crane onto its feet in a controlled manner. For instance, attach a hoist chain to the I-beam
and then slowly raise the beam until the crane rotates to stand on its feet. Alternatively, raise the crane
with a fork truck. Position the forks under the I-beam and slowly raise the beam until the crane rotates
onto its feet in a controlled manner.
Step 5: Connect the casters to the legs (instructions show standard
casters).Attach each caster to the foot of each leg using the
hardware shown in Fig. 5B. Raise the crane 8 to 10 inches off of the
ground with a fork lift or hoist. Position a caster underneath each foot
as shown in Figures 5A & 5B below. Slide a lock washer (8) followed by
a flat washer (10) onto a 1-1/4in. bolt (5), and feed the bolt up through
the bolt holes in the caster and foot cap (photo D). Put a lock washer
(8) onto the bolt and fasten a nut (7) to the end of the bolt.
FIG. 5D: AHS 6k & 8k
models
1
1
/
2
in. -13 nylon insert lock
nut
2 8in. x 3in. phenolic 4-way
swivel lock caster
8
1
/
2
in. -13 x 1
1
/
2
in. HHCS #2
zinc-plated bolt
Approach the crane with a fork truck from
this side, and slide the forks under the I-
beam.
Slowly raise the beam and slowly drive
forward until the crane stands on its feet.
DO NOT raise the beam unless
all other persons have moved to a location
away from and behind the fork truck.
FIG. 5B: AHS 10-15-10
1 ½ in. – 13 x 2in. HHCS #5
zinc-plated bolt
2 Ø8in. x 3in. ductile steel
caster
3 Batwing caster position
lock
4 ½ in. – 13 lock nut
FIG. 5C: AHS 2k
and 4k models
2 Leg Assembly
4 GFN-8/2-S caster
8
5
/
16
in. zinc-plated lock
washer
9
5
/
16
in. – 18 x ¾ in. HHCS #2
zinc-plated bolt
10
5
/
16
in. zinc-plated USS flat
washer
1
2
3
4
8
2
1
10
4
8
9
2
FIG. 5E: Dual pneumatic
casters
2 Dual pneumatic caster
3 Caster mount bracket
5
1
/
2
” -13 zinc-plated hex
nut
6
1
/
2
” zinc finish flat washer
FIG. 5A: Caster installation
4
7
3
6
5
2
4
7
17
15
16
4
1
/
2
” -13 x 1
1
/
4
” HHCS #2 zinc-
plated bolt
7
1
/
2
” plain finish lock washer
(medium split)
15
5
/
16
” plain finish lock washer
(medium split)
16
5
/
16
” -18 x
3
/
4
” HHCS #2, zinc-
plated
17
5
/
16
” zinc plated flat washer
