4
LOADING INSTRUCTIONS
The load capacity, which appears on the
data label (see p. 11, label 287) of your unit, is the
net maximum weight the table will support. All
loads applied to the table must be centered and
evenly distributed, and assumes the load is
centered. DO NOT exceed the capacity because
permanent damage or injury might occur.
OPERATING INSTRUCTIONS
This unit is equipped with a constant
pressure ("deadman" type) push button controller.
The buttons are marked, "RAISE" and "LOWER".
Press the "RAISE" button to elevate the deck of
the table. When the button is pressed, the
motor air supply valve opens and air pressure
causes the cylinder to extend. Cylinder extension
raises the deck. Always stand to the side of the
table while operating the cylinder and keep clear
of moving parts. The platform will rise as long as
the "RAISE" control is pressed. When the button is
released, the deck will maintain its present
position. Releasing the button allows the valve to
close and prevents further air flow, i.e. closes the
pilot-operated motor air supply valve.
Pressing the "LOWER" control button
energizes the lowering solenoid valve. This allows
the cylinders to retract as oil returns to the
reservoir. As with the RAISE button, releasing the
LOWER button causes the deck to stop moving
and to maintain its current elevation. Be certain
no person or object is in the way while the unit
descends.
If the unit is overloaded, the deck will not
rise. Instead, the relief valve will open due to
excessive pressure buildup ans oil will bypass the
cylinder and flow into the reservoir.
Always remember: 1) the motor operates only
while the "RAISE" button is pressed; and 2) the
lowering solenoid valve is energized only while the
"LOWER" button is pressed.
SAFETY INSTRUCTIONS TO THE OPERATOR
1.)
Always center and evenly distribute loads
placed on the table.
2.)
DO NOT use the table if repairs are necessary.
Only use the table if it is in normal operating
condition.
3.) Tag the unit "Out of service" and
noti
fy
maintenance personnel if you notice anything
unusual during operation, such as binding,
odd pump noises, etc.
4.)
Do not continue to press the "UP" control if
the unit does not elevate. The motor and/or
pump might be permanently damaged as a
consequence.
ORDERING REPLACEMENT OR EXTRA PARTS
Vestil Manufacturing Co. company is
commit
ted to using high quality parts in all of our
products.
Vestil is not responsible for any
equipment failure that results from the use of
unapproved replacement parts. To order
replacement (or spare) parts contact
Customer
Service at the telephone number of email address
published on the cover page of theis manual. To
expedite your request, be prepared with the serial
number of your table, which appears on the data
label (#287 on p. 11). Only refer to part numbers
listed in this Owner's Manual.
