2
INSTALLATION INSTRUCTIONS
Review this Owner's Manual in its entirety before beginning the installation.
The following tools are required to install the table:
- A fork truck or hoisting means.
- Lag bolts, masonry drill, ma
sonry bit, wrench for lag bolt, grout, and steel shims.
1) Read each label applied to the table (see "Label placement diagram" on p. 11). Confirm that every
label shown in the diagram is present.
2) Move the table to the desired installation location. Support the base of the table while moving it.
3) Be sure maintenance prop is in place before getting under platform.
4) If mounting the power unit externally, blow out the connecting hydraulic line with compressed air.
5) Install the lift table on a level, even surface.
a) Anchor the table to the floor with appropriately-matched anchor bolts.
b) Measure the diameter of the bolt holes in the base of the frame, and install bolts that are at
least 4in. long to anchor the table to the floor.
c) Shim the table to level it. Grout under the base of the table to provide additional resistance
to warping and bending forces applied to the base between shims. Grout around the entire
perimeter of the base frame.
6) Connect main air supply to the control pedestal. If no control pedestal is supplied, see schematic
for air inlet. NOTE: Use only clean, dry air. Use of a filter/regulator is recommended.
7) Operate the table through a few RAISE-LOWER cycles (fully raise the deck and then lower
it completely according to the instructions on p. 3); then check the oil level. Add oil if necessary
[see Oil specifications on p. 10 (under "Yearly") of this manual].
INSTALLATION PROCEDURE
