TABLE OF CONTENTS Rev. 5/28/2025 AHA MANUAL
TABLE OF CONTENTS Copyright 2020 Vestil Manufacturing Co. Page 12 of 24
FIGURE 8: Exploded View of AHA-4-15-8, AHA-4-15-10, & AHA-4-15-12
Item
Part no.
Description
Quantity
1
28-014-272
Aluminum 4k gantry casting
2
2
28-112-007
Pin, retaining, ¾ in. x 6 in. usable length
2
3
28-514-230
28-514-231
28-514-232
Adjustable upright weldment: (when ordering
replacements, only sold as a pair)
AHA-4-15-8
AHA-4-15-10
AHA-4-15-12
2
2
2
4
33626
½ in. zinc-plated lock washer
8
5 & 12
11134585
½ in. – 13 x 2½ in.A325 galvanized structural nut & bolt
½ in. – 13 A325 galvanized structural nut & bolt
8
6
45286
1
/
8
in. x 2
5
/
8
in. #11 hitch pin clip
4
7
28-112-031
Pin, clevis, ¾ in. x 4
1
/
4
in. usable length
4
8
33082
3
/
8
in. zinc plated SAE flat washer
32
9
11107
3
/
8
in. – 16 x 1¼ HHCS #2 zinc-plated bolt
16
10
33622
3
/
8
in. zinc plated lock washer
16
11
36106
3
/
8
in. – 16 zinc plated hex nut
16
13
28-014-236
10 in. (H) x 4.66 in. (W) x 180 in. (L) aluminum I-beam
1
14
28-516-054
I-beam clamp weldment
4
15
08-025-007
3
/
8
in. – 16 UNC threaded knob, TT-18-PED
6
16
28-514-221
4k leg tube weldment
4
17
GFN-8/2-S-4PSL
(16-132-249)
Glass filled nylon 4-position swivel locking caster
4
28-006-229
