SPECIFICATIONS
Dimensions, net weight, and capacity information for each AHA-series crane is provided in the tables on pages 2,
3, and 4. However, minor changes in product design might alter specifications, particularly dimensions and net
weight. To provide instant access to up-to-date information, documents that provide specifications for AHA series
cranes are available online to anyone who visits the Vestil website. Acquire the appropriate specifications document
by opening this webpage: https://www.vestil.com/product.php?FID=522 . Click the “Specifications” tab. Scroll the
page to the entry for the specific model you purchased. Click the button in the “PDF” column that looks like a pencil
inside a blue-bordered box. A PDF file will open. This file is the specifications document. Print a copy of the document
as soon as your crane is delivered and keep it with your copy of this manual. If you encounter difficulties while trying
to obtain a copy of the specifications document, contact Technical Service. Contact information is provided on the
cover page of this manual.
Model
A:
Overall
width
B:
Overall
Beam
Length
C:
Usable
beam
length
D:
Beam
height
E:
Overall height
F:
Usable height
range
Capacity
Net
Weight
AHA-2-8-8
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(74-104) in.
(188-264.2) cm
(68 – 98) in.
(30.9 – 44.5) cm
2,000 lb.
909 kg
276 lb.
kg
AHA-2-8-10
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(98-128) in.
(249 - 325) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
277 lb.
kg
AHA-2-8-12
53
3
/
4
in.
136.5 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
6 in.
15.2 cm
(120 – 150) in.
(304.8 – 381) cm
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
287 lb.
kg
AHA-2-10-8
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(74 – 104) in.
(188 – 264.2) cm
(68 – 98) in.
(172.7 – 248.9)cm
2,000 lb.
909 kg
272 lb.
kg
AHA-2-10-10
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(98 – 128) in.
(248.9 – 325.1) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
293 lb.
kg
AHA-2-10-12
53
3
/
4
in.
136.5 cm
120 in.
304.8 cm
96
1
/
4
in.
244.5 cm
6 in.
15.2 cm
(120 – 150) in.
(304.8 – 381) cm
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
305 lb.
kg
AHA-2-12-8
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(76 – 106) in.
(193 – 268.2) cm
(68 – 98) in.
(172.7 – 248.9) cm
2,000 lb.
909 kg
307 lb.
kg
AHA-2-12-10
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(100 – 130) in.
(254 – 330.2) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
315 lb.
kg
AHA-2-12-12
53
13
/
16
in.
136.7 cm
144 in.
365.8 cm
120
1
/
4
in.
305.4 cm
8 in.
20.3 cm
(122 – 152) in.
(309.9 – 386.1) kg
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
327 lb.
kg
AHA-2-15-8
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(76 – 106) in.
(193 – 269.2) cm
(68 – 98) in.
(172.7 – 248.9) cm
2,000 lb.
909 kg
360 lb.
kg
AHA-2-15-10
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(100 – 130) in.
(254 – 330.2) cm
(92 – 122) in.
(233.7 – 309.9) cm
2,000 lb.
909 kg
405 lb.
kg
AHA-2-15-12
53
13
/
16
in.
136.7 cm
180 in.
457.2 cm
156
1
/
4
in.
396.9 kg
8 in.
20.3 cm
(122 – 152) in.
(309.9 – 386.1) kg
(114 – 144) in.
(289.6 – 365.8) cm
2,000 lb.
909 kg
412 lb.
kg
AHA-4-8-8
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(76
1
/
8
– 106
1
/
8
) in.
(193.5 – 269.7) cm
(68
1
/
8
– 98
1
/
8
) in.
(173.2 – 249.4) cm
4,000 lb.
1,818 kg
353 lb.
kg
AHA-4-8-10
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(100
1
/
8
– 130
1
/
8
) in.
(254.3 – 330.5) cm
(92
1
/
8
– 122
1
/
8
) in.
(234 – 310.2) cm
4,000 lb.
1,818 kg
346 lb.
kg
AHA-4-8-12
53
15
/
16
in.
137 cm
96 in.
243.8 cm
72
1
/
4
in.
183.5 cm
8 in.
20.3 cm
(122
1
/
8
– 152
1
/
8
) in.
(310.2 – 386.4) kg
(114
1
/
8
– 144
1
/
8
) in.
(289.9– 366.1) cm
4,000 lb.
1,818 kg
372 lb.
kg
A
B
C
D
E
F
