Vestil AEC-3660-3-GFN handleiding
Handleiding
Je bekijkt pagina 4 van 6
rev. 5/31/2017
Copyright 2017 Vestil Manufacturing Corp. Page 4 of 6
ITEM NO
PART NO DESCRIPTION QTY
1 16-514-295 WELDMENT, FRAME 1
2 16-132-262
16-132-026
6 X 2 GLASS FILLED NYLON SWIVEL CASTER (AEC-3660-3-GFN)
6 X 2 MOLD ON RUBBER SWIVEL CASTER (AEC-3660-3-MR)
4
3 16-516-024 SUB-ASSEMBLY, HITCH 1
4 16-014-498 FRAME, TUBE, GALVANIZED PERFORATED 4
5 16-016-235 BRACKET, BLOCKER, FORMED 6
6 11209 ½-13 x 1 ½” LG HHCS – ASTM A307 GRADE A, ZINC PLATED 2
7 33011 FLAT WASHER, USS, PLAIN FINISH, ½” 4
8 33626 LOCK WASHER Z PLATED, ½” 2
9 36110 HEZ NUT Z PLATED, ½-13 3
10 16-516-021 WELDMENT, TOW BRACKET 1
11 99-145-133 HEX CAP SCREW, GRADE 8, YELLOW ZINC, ½”-13 X 8” 1
12 16-132-263
16-132-027
6 X 2 GLASS FILLED NYLON RIGID CASTER (AEC-3660-3-GFN)
6 X 2 MOLD ON RUBBER RIGID CASTER (AEC-3660-3-MR)
2
13 16-013-155 DECK, CART 2
14 16-025-025 HANDLE, FORMED, HT/ERGO HANDLE 1
15 33012 FLAT WASHER, LOW CARBON, ZINC FINISH, ½” 2
16 33625 LOCK WASHER, MEDIUM SPLIT, PLAIN FINISH, ½” 1
17 11105 HEX BOLT, GRADE A, ZINC PLATED, 3/8”-16 X 1” 2
18 33008 FLAT WASHER, LOW CARBON, USS, ZINC PLATED, 3/8” 36
19 33622 SPLIT LOCK WASHER, CARBON STEEL, MEDIUM ZINC FINISH, 3/8”
18
20 36106 HEX NUT, GRADE A, ZINC PLATED, 3/8-16 18
21 31-024-014 PLUG, SQUARE TUBING 4
22 11115 HHCS, #2 Z PLATED, 3/8- 16 X 3 LG. 16
23 11001 ¼-20 UNC X ½ LG, HHCS, #2 Z-PLATED 16
24 33004 FLAT WASHER, USS, ZINC PLATED, ¼” 32
25 37018 NYLON LOCK NUT, GRADE 2, ZINC FINISH, 1/4”-20 16
26 99-145-134 SQUARE DOUBLE WIRE, SNAPPER PIN, 3/8” X 2-1/4” 16
27 99-112-006 CLEVIS PIN 6
28 65076 1/8” X 1” COTTER PIN, Z-PLATED 6
