9
The appliance can be used as an extractor (extraction of vapors) or as an absorber (vapors are
ltered and directed back into the room). Cooker hood models without engine operate exclusively
as an extractor and must be connected to an external engine (not included). Relevant connection
instructions are provided with the external engine
Vapors are extracted through an extraction pipe mounted on the joint ange.
Extraction pipe’s diameter must be equal to joint ange’s diameter.
Caution! Extracting pipe is not included with the appliance, it needs to be purchased
separately.
In the horizontal section, the pipe must have slight upward inclination (approx. 10°), to
facilitate air outow. If the cooker hood is equipped with charcoal lters, they must be
removed.
Connect the cooker hood to the ventilation duct with an extraction pipe of diameter
matching the size of the cooker hood’s outlet (joint ange).
Usage of pipes with smaller diameter will decrease suction capacity and signicantly
increase cooker hood’s noise level. Manufacturer cannot be held liable for this condition.
You must install a charcoal lter in order to use the appliance in this variant. You can buy
a charcoal lter from the manufacturer or from an authorized service agent. Sucked air is
cleaned of grease and odors and is directed back into the room through grills in the upper
part of the hood.
Minimum distance between the surface of the heating device, where the dishes are placed, and the
lowest part of the cooker hood must be no less than 55 cm for electric cookers and not less than 65
cm for gas or hybrid cookers.
If gas cooker installation instructions recommend a larger distance,comply with these instructions.
Cooker hood ceilings. It is necessary, however, to seek expert advice from a qualied technician, to
make sure that the used materials are suitable for a particular type of wall or ceiling. is equipped
with xing anchors appropriate for standard walls and Wall or ceiling must be strong enough to
carry the weight of the cooker hood.
Use the shortest possible ducting.
Use ducting with as few bends as possible (maximum bend radius: 90°).
Avoid ducting with signicant changes of diameter.
Use ducting with internal surface as smooth as possible.
Ducting must be made of material compliant with all applicable standards.
Operations
Cooker hood operating as an extractor
Cooker hood operating as an absorber
Cooker hood installation
PL EN
