English - 10 -
When using the wall mount bracket
Your TV is also prepared for a VESA-
compliant wall mount bracket. If it is
not supplied with your TV, contact
your local dealer to purchase the
recommended wall mount bracket.
Holes and measurements for the wall
mount bracket installation;
A VESA WALL MOUNT MEASUREMENTS
B
Hole Paern
Sizes (mm)
W H
200 200
C Screw Sizes
F G
D Length (X)
min. (mm) 7 5
max. (mm) 10 6
E Thread (Y) M6
Antenna Connection
Connect the aerial or cable TV plug
to the aerial input (ANT) socket or
satellite plug to the satellite input
(LNB) socket located on the rear-left
side of the TV.
Rear-left side of the TV
ANT
LNB
If you want to connect a device to the TV, make
sure that both the TV and the device are turned o
before making any connection. After the connection
is done, you can turn on the units and use them.
