Page 18
Chapter 5 Post-Installation Checklist
After the (9X-R70 Repeater has been mechanically installed and all electrical connections have
been made, power may now be applied and the repeater checked for proper operation.
5.1 Applying Power
Before applying power to the repeater, make sure all boards are securely seated in the appropriate
connectors on the backplane and that all RF cables are securely connected.
Turn ON the circuit breaker controlling the AC outlet that is supplying power to the repeater Power
Supply Module.
5.2 Verifying Proper Operation
Operation of the repeater can be veried by:
• observing the state of the 8 LEDs located on the front panel, and
• exercising radio operation.
Some repeater components can become extremely hot during operation.
Turn off all power to the repeater and wait until sufciently cool before touch-
ing the repeater.
5.2.1 Front Panel LEDs
After turning ON the repeater power (or after a repeater reset), the 8 LEDs on the repeater
front panel:
• Light for about one second to indicate that they are functional, then
• Go off for one second, then
• Indicate the operational status of the repeater.
5.3 Archiving
5.3.1 Copying the Repeater Codeplug Data to a Computer
Backup the repeater’s codeplug data by using the Programming Software on a computer.
