Veritas Power Stitch 32 TITAN Handleiding (56 Pagina's)

Handleiding

14

Winding the bobbin

1. Slide the bobbin and the spool pin cap onto the

horizontal spool pin. For better sewing quality,

choose a spool pin cap of a suitable size for the

thread and attach it next to the bobbin.

①

Large spool pin cap

②

Small spool pin cap

2. Pull the thread from the spool through the upper

thread guide.

3. Wind the thread clockwise around the bobbin

thread guide.

4. Lead the thread from the inside through a hole of

the empty bobbin as illustrated. Place the bobbin

on the bobbin winder spindle. Align the notch with

the spring of the bobbin winder spindle.

①

Notch

②

Bobbin winder spindle spring

5. Push the bobbin to the right.

For good sewing results, the threading must be carried out correctly. Otherwise several problems will

occur.

Note

When the bobbin winder spindle is pushed to the right, it’s in bobbin winding mode and the device is not allowed

to sew and the handwheel will not turn. To start sewing, you must push the bobbin winder spindle back to the

left.

①

②
