32
EN
4. Loosen 1 screw as shown in the gure below to remove
the gap cover at the top of the appliance. Remove the
cover from the small end cap on the door and remove the
door socket and cable connection.
5. Place the door socket in the round opening of the door
and attach the cover to the small end cap.
6. Lift the fridge door about 50 mm to remove it from the
appliance.
7. Loosen the 3 screws holding the middle hinge and remove
the hinge.
8. Lift the freezer door about 50 mm to remove it from the
appliance.
9. Remove the adjustable front supports under the lower
hinge. Then loosen the 4 screws holding the lower hinge
and remove the hinge from the appliance.
10. Install the removed parts on the other side of the
appliance. Pull the door socket, as shown in the gure
below, and install it in the corresponding position on the
other side.
