24 EN

PUTTING INTO OPERATION

!

Attention! Make sure the device is switched off and the power plug is discon-

nected before you start!

1 Unpack the appliance, set it up and use the transport castors 14 to move it to

the place you want. To do this, lift slightly on the right-hand side. Remove battery

protection and protective foil from remote control 13.

2 Open filter compartment7 and remove coarse dust filter 9.

3 Remove and open HEPA filter10.

4 Re-insert opened HEPA filter 10 and coarse dust filter 9 and close filter compart-

ment 7.

5 Open evaporator compartment 3 and remove water tank 4.

6 Open water tank 4 and fill up to the MAX marker with cold water.

7 Close water tank4 securely and place into water tray 6, close evaporator com-

partment 3.

8 Adjust display 1 to the position you want (3 positions possible).

9 Adjust cable connector to the length you want by winding/unwinding in cable com-

partment 11. Connect power plug to mains and switch appliance on using on/off

switch 2 or remote control 13.

i

It can take approx. 60 seconds for the appliance to start up and the red light

on the display to go out. You will be able to hear a noise (gurgling), which is not a

quality defect.

1 Display

2 On/off switch

3 Evaporator compartment

4 Water tank

5 VentWave disk stack

6 Water tray

7 Filter compartment

8 UVC lamp (pre-installed)

9 Coarse dust filter

10 HEPA filter

11 Cable compartment

12 Hygiene disk (pre-installed)

13 Remote control

14 Transport castors

OVERVIEW

1

2

3

4

5

7

11

6

14 12

13

9

8

10

AH902
