8 Technical specications

Light source 7 × RGBW 4-in-1 LED, 60 W

Optical properties Beam angle 6°…50°, adjustable via motorised

zoom

Light output 95,000 lux @ 3 m (6°)

Rotation angle (pan), max. 540°

Inclination angle (tilt), max. 220°

Control protocols DMX512

Control DMX, buttons and display

Number of DMX channels 9, 34, 23 or 51

Input connections Power supply Lockable input socket (Power

twist)

DMX control XLR chassis plug, 3-pin

XLR chassis plug, 5-pin

Output connections Power supply of fur‐

ther devices

Lockable output socket (Power

twist)

Output current, max.: 6 A

DMX control XLR chassis socket, 3-pin

XLR chassis socket, 5-pin

Power consumption 420 W

Supply voltage

100 - 240 V 50/60 Hz

Fuse 5 mm × 20 mm, 4 A, 250 V, fast

blow

International Protection Rating IP20

Dimensions (W × H × D) 337 mm × 400 mm × 246 mm

Weight 11.5 kg

Ambient conditions Temperature range 0 °C…40 °C

Relative humidity 20%…80% (non-condensing)

Light source type LED

Light output 420 W

Colour mix RGBW

Motorised focus No

Motorised zoom Yes

Static gobos No

Rotating gobos No

Iris No

Prism No

337 mm

246 mm

400 mm

Further information

Technical specications

Hero Pixel Wash 760FX

Moving Head
