Channel Value Function

18 000…255 Eects speed from slow (0) to fast (255)

19 000…255 Red background intensity, 0 to 100%

20 000…255 Green background intensity, 0 to 100%

21 000…255 Blue background intensity, 0 to 100%

22 000…255 White background intensity, 0 to 100%

23 000…250 No function

251…255 Reset if the value is transmitted for at least 5 seconds

7.12 Functions in 51-channel DMX mode

Channel Value Function

1 000…255 Rotation (pan) (0° up to the maximum value of the Pan range)

2 000…255 Fine adjustment of rotation (pan)

3 000…255 Inclination (tilt) (0° up to the maximum value of the Tilt area)

4 000…255 Fine adjustment of inclination (tilt)

5 000…255 Speed of rotation (pan) and inclination (tilt), fast (0) to slow (255)

6 000…255 Zoom, 0 to 100%

7 Zoom rotation

000…127 Static position of the rotating lens unit (0 to 60 °)

128…190 Clockwise rotation, decreasing speed

191…192 Stop rotation

193…255 Counter-clockwise rotation, increasing speed

8 000…255 Intensity of dimmer gradient from dark to bright

9 Strobe

000…003 LEDs o

004…103 Constantly increasing brightness, increasing speed (dimmed bright, quickly dark)

104…107 LEDs on

108…207 Impulse eect, increasing speed (dimmed light and dark)

208…212 LEDs on

213…225 Strobe eect (low speed)

226…238 Strobe eect (medium speed)

239…251 Strobe eect (high speed)

252…255 LEDs on

10 000…255 Red intensity, 0 to 100%

11 000…255 Green intensity, 0 to 100%

12 000…255 Blue intensity, 0 to 100%
