USER MANUAL
912400575012UM
WWW.VARI-LITE.COM
TABLE 1. MENU FUNCTIONS
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 LEVEL 6 DEFAULT
DMX
Data
Ch 1 - Intensity XXX (Value)
Ch 2 - Intensity Fine XXX (Value)
…All functions
Pan /Tilt
Swap Pan / Tilt
Off (Default)
On
Invert Pan
Off (Default)
On
Invert Tilt
Off (Default)
On
DMX Mode
16-bit 1 Cell (Default)
16-bit 7 Cell
8-bit 1 Cell
8-bit 7 Cell
No Data
Last output hold
Black out (Default)
Fixture
Status (No Errors... or displays a list of errors)
Reboot Fixture Are you sure?
Version VXXX
Fixture Hours XXXXXX h
Crossload
(software)
Send
Service
Service Settings Optics Offset Zoom
Diagnostics
Fan Check
LED Temp
Manual Control
Intensity Value 0 - 255 (Default 0)
Intensity fi ne Value 0 - 255 (Default 0)
…All functions All functions (Default 0)
Te st
All Test (Run ‘ALL TEST’ )
Pan / Tilt Test (Run ‘PAN/TILT TEST’ )
Test Channel
Intensity (Run Intensity test)
Pan (Run Pan test)
…All functions …
Encoder Pan XXXXXXX - Displays Pan Encoder
Encoder Tilt XXXXXXX - Displays Tilt Encoder
Address
Address — DMX address setting. To select DMX Address, press the ENTER button to confi rm. Use the UP/DOWN
button to adjust the address from 001 to 512, press the ENTER button to store. Press the MENU button back to
the last menu or let the unit idle one minute to exit menu mode.
Configure
To select Confi gure, press the ENTER button to confi rm, use the UP/DOWN button to select LED, Tilt, Pan, Dis-
play or Reset Defaults.
LED
To select LED, press the ENTER button to confi rm. Use the UP/DOWN button to select LED Hours, Dimming
Curve, Dimming Speed, White Balance, Output / Fan Mode or Frequency, press the ENTER button to store. Press
the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Press the ENTER
button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode.
LED Hours — Select LED Hours, press the ENTER button to confi rm, LED Hours will show on the display,
press the MENU button back to exit.
