17
USER MANUAL
912400575012UM
WWW.VARI-LITE.COM
TABLE 5.
8-BIT 7
CELL
CHANNEL FUNCTION DEFAULT RANGE DESCRIPTION
37
Strobe Control
0 - 255
0 - 255
0 - 5
6 - 10
11 - 15
16 - 20
21 - 25
26 - 255
Control Channel for strobing functions.
Open* Open
Closed
Normal Strobe
Random Strobe
Random Sync
Reserved Values
38
Focus Timing
255 0 - 255
Adjustment of fi xture timing to control Pan/Tilt mecha-
nisms.
39
Optics Timing
255 0 - 255
Adjustment of fi xture timing to control lensing mecha-
nisms.
40
Color Timing
255 0 - 255
Adjustment of fi xture timing to control color mecha-
nisms.
41
Control Channel
0
0 - 255
0 - 5
6 - 10
11 - 15
16 - 20
21 - 25
26 - 30
31 - 35
36 - 40
41 - 45
46 - 50
51 - 55
56 - 60
61 - 65
66 - 70
71 - 75
76 - 80
81 - 85
86 - 90
91 - 100
101 - 110
111 - 120
121 - 130
131 - 255
Control Channel used for full fi xture settings,
lamp controls, and miscellaneous modes.
Set discrete value of desired effect, wait >3 seconds,
then set value to 0 (Idle).
Idle (Default)
Full Luminaire ReCal - Also Used to Wake fi xture up
from shutdown
Reserved Values
Reserved Values
Fixture Shutdown
Display - Menu ON
Display - Menu OFF
Dimming Curve Linear
Dimming Curve S-Curve
Dimming Curve Square Curve (Default)**
Reserved Values
Reserved Values
Dimmer Snap On (Fast snaps)
Dimmer Snap Off (Default) (Smooth Dimming)
Color Calibration on
Color Calibration off (Default)
Standard Mode - Fixture operates at maximum output
(Default)
Studio Mode - Reduced output with lower fan settings
Whisper Mode - Redcued output with lower fan settings
Silent mode - Redcued output Fans deactivates
Fan On (Default)
Fan Auto
Reserved Values
TABLE 6. DMX MAP - ALL
CHANNEL 16-BIT 1 CELL 16-BIT 7 CELL 8-BIT 1 CELL 8-BIT 7 CELL
1 Intensity High Intensity High Intensity Intensity
2 Intensity Low Intensity Low Pan High Pan High
3 Pan High Pan High Pan Low Pan Low
4 Pan Low Pan Low Tilt High Tilt High
5 Tilt High Tilt High Tilt Low Tilt Low
6 Tilt Low Tilt Low Zoom Zoom
7 Zoom Zoom Red Red
8 Red High Red High-1 Green Green
9 Red Low Red Low-1 Blue Blue
10 Green High Green High-1 White White
11 Green Low Green Low-1 Color Preset Red
12 Blue High Blue High-1 Strobe Speed Green
13 Blue Low Blue Low-1 Strobe Control Blue
14 White High White High-1 Focus Timing White
15 White Low White Low-1 Optics Timing Red
