15
USER MANUAL
912400575012UM
WWW.VARI-LITE.COM
TABLE 4. 8-BIT 1 CELL
CHANNEL FUNCTION DEFAULT RANGE DESCRIPTION
17
Control Channel
0
0 - 255
0 - 5
6 - 10
11 - 15
16 - 20
21 - 25
26 - 30
31 - 35
36 - 40
41 - 45
46 - 50
51 - 55
56 - 60
61 - 65
66 - 70
71 - 75
76 - 80
81 - 85
86 - 90
91 - 100
101 - 110
111 - 120
121 - 130
131 - 255
Control Channel used for full fi xture settings, lamp con-
trols, and miscellaneous modes. Set discrete value of de-
sired effect, wait >3 seconds, then set value to 0 (Idle).
Idle (Default)
Full Luminaire ReCal - Also Used to Wake fi xture up
from shutdown
Reserved Values
Reserved Values
Fixture Shutdown
Display - Menu ON
Display - Menu OFF
Dimming Curve Linear
Dimming Curve S-Curve
Dimming Curve Square Curve (Default)**
Reserved Values
Reserved Values
Dimmer Snap On (Fast snaps)
Dimmer Snap Off (Default) (Smooth Dimming)
Color Calibration on
Color Calibration off (Default)
Standard Mode - Fixture operates at maximum output
(Default)
Studio Mode - Reduced output with lower fan settings
Whisper Mode - Redcued output with lower fan settings
Reserved Values
Fan On (Default)
Fan Auto
Reserved Values
TABLE 5. 8-BIT 7 CELL
CHANNEL FUNCTION DEFAULT RANGE DESCRIPTION
1 Intensity High 0 0 - 255 8 Bit control of Dimming
2 Pan High
32767 0-65535 16 Bit Movement control PAN, 720° end to end travel
3 Pan Low
4 Tilt High
32767 0-65535 16 Bit Movement control Tilt, 220° end to end travel
5 Tilt Low
6 Zoom 128 0 - 255 Zoom control, Narrow 0 >>>>> 255 Wide
7 Red High 1 0 0 - 255 8 Bit control of color
8 Green High 1 0 0 - 255 8 Bit control of color
9 Blue High 1 0 0 - 255 8 Bit control of color
10 White High 1 0 0 - 255 8 Bit control of color
11 Red High 2 0 0 - 255 8 Bit control of color
12 Green High 2 0 0 - 255 8 Bit control of color
13 Blue High 2 0 0 - 255 8 Bit control of color
14 White High 2 0 0 - 255 8 Bit control of color
15 Red High 3 0 0 - 255 8 Bit control of color
16 Green High 3 0 0 - 255 8 Bit control of color
17 Blue High 3 0 0 - 255 8 Bit control of color
18 White High 3 0 0 - 255 8 Bit control of color
19 Red High 4 0 0 - 255 8 Bit control of color
20 Green High 4 0 0 - 255 8 Bit control of color
21 Blue High 4 0 0 - 255 8 Bit control of color
22 White High 4 0 0 - 255 8 Bit control of color
23 Red High 5 0 0 - 255 8 Bit control of color
24 Green High 5 0 0 - 255 8 Bit control of color
25 Blue High 5 0 0 - 255 8 Bit control of color
