UsEr manUaL
www.Vari-LitE.com
VL800 EVEntprofiLE
30
TABLE 7. MENU SYSTEM
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 LEVEL 6 DEFAULT
TEST
All Test (Run ‘ALL TEST’)
Pan/Tilt Test (Run ‘PAN/TILT TEST’)
Test Channel
Intensity (Run Intensity test)
Pan (Run Pan test)
……All functions ……
Encoder Pan XXXXXXX - Displays Pan Encoder
Encoder Tilt XXXXXXX - Displays Tilt Encoder
MANUAL/
PRESET
Preset
Playback
Select preset 1 to 20
Intensity 0 - 255
User Preset
Setting
Intensity 0 - 255
Shutter / Strobe 0 - 255
Pan 0 - 255
Tilt 0 - 255
Cyan 0 - 255
Yellow 0 - 255
Magenta 0 - 255
CTO 0 - 255
Color Wheel 0 - 255
Gobo 1 0 - 255
Gobo 2 0 - 255
Prism 0 - 255
Zoom 0 - 255
Focus 0 - 255
Iris 0 - 255
Frost 0 - 255
Frame 1A 0 - 255
Frame 1B 0 - 255
Frame 2A 0 - 255
Frame 2B 0 - 255
Frame 3A 0 - 255
Frame 3B 0 - 255
Frame 4A 0 - 255
Frame 4B 0 - 255
Frame Rotate 0 - 255
Store 1 >>>>>>>>>> 20 Are your sure (Yes/No)
Clear 1 >>>>>>>>>> 20 Are your sure (Yes/No)
ADDRESS
To select Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the address from 001
to 512, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one
minute to exit menu mode.
CONFIGURE
To select Configure, press the ENTER button to confirm, use the UP/DOWN button to select LED, Movement,
Display, Focus Compensate or Reset Defaults.
