TABLE 3. CLONE
DMX PARAMETER DEFAULTS RANGE DESCRIPTION
18
Gobo Wheel 2
(Fixed)
0
0-255 8-bit control of Gobo Wheel for movement options see channel 22
0 Open - No Gobo
1 Gobo 1 (Leafy Breakup)
2 Gobo 2 (Honeycomb)
3 Gobo 3 (Radial Breakup)
4 Gobo 4 (Grid)
5 Gobo 5 (Circle of dots)
6 Gobo 6 (Punchcard)
7 Gobo 7 (Vertical Bars)
8 Gobo 8 (Medium Circle
9 Open - No Gobo
10 - 13 Gobo 1 (Leafy Breakup) Shake Fast >>>>> Slow
14 - 34 Gobo 2 (Honeycomb) Shake Fast >>>>> Slow
35 - 55 Gobo 3 (Radial Breakup) Shake Fast >>>>> Slow
56 - 76 Gobo 4 (Grid) Shake Fast >>>>> Slow
77 - 97 Gobo 5 (Circle of dots) Shake Fast >>>>> Slow
98 - 118 Gobo 6 (Punchcard) Shake Fast >>>>> Slow
119 - 139 Gobo 7 (Vertical bars) Shake Fast >>>>> Slow
140 - 160 Gobo 8 (Medium Circle) Shake Fast >>>>> Slow
161-185 Open - No Gobo
186 - 216 Gobo Wheel Rotate Clockwise S>>>>F
18
Gobo Wheel 2
(Fixed)
continued
0
217-220 Stop No Rotation
221-251 Gobo Wheel Rotate Counter Clockwise S>>>>>F
252-255 Stop No Rotation
19 Iris 0
0-255 Iris size control
0 - 200 Iris beam size open to closed
201 - 255 Iris pulse slow to fast
20 Frame 1A 0 0 - 255 Controls Framing Shutter 1A from Open to Full (DMX 0-255).
21 Frame 1B 0 0 - 255 Controls Framing Shutter 1B from Open to Full (DMX 0-255).
22 Frame 2A 0 0 - 255 Controls Framing Shutter 2A from Open to Full (DMX 0-255).
23 Frame 2B 0 0 - 255 Controls Framing Shutter 2B from Open to Full (DMX 0-255).
24 Frame 3A 0 0 - 255 Controls Framing Shutter 3A from Open to Full (DMX 0-255).
25 Frame 3B 0 0 - 255 Controls Framing Shutter 3B from Open to Full (DMX 0-255).
26 Frame 4A 0 0 - 255 Controls Framing Shutter 4A from Open to Full (DMX 0-255).
27 Frame 4B 0 0 - 255 Controls Framing Shutter 4B from Open to Full (DMX 0-255).
28 Frame Rotate 128 0 - 255 Controls Framing Shutter mechanism from +/- 90°
29 Triangular Prism 0 - 255
0 - 255 Controls Prism mechanism with following values.
0 - 5 Open
6 - 10 Index
11 - 15 Rotate Normal
16 - 20 Rotate with Mega Stepping
21 - 255 Reserved Values
30
Prism Index/Rot
High Byte
32767
0 - 65535 16-bit control of prism rotation and index.
0 - 32756 Rotate Fast to Slow <<<
31
Prism Index/Rot
Low Byte
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
