USER MANUAL
WWW.VARI-LITE.COM
VL5LED WASH
14
TABLE 1. SMART COLOR CONTROL
DMX CHANNEL
BLADE LED GROUP
PARAMETER DEFAULTS RANGE DESCRIPTION
0
1
(DEFAULT)
16
26 26 26
Blade Light - Color
Preset
0
173 - 211 Color Chase 4 (S>>>>>F)
212 - 250 Color Chase 5 (S>>>>>F)
251 - 255 No Color
27 27 27
Blade Light - Macro
Effects
0
0 - 5
No effect static color based on Blade color
preset channel uses blade effect fade &
speed channels to control parameters of
chase
6 Strobe Sync full
7 Strobe Random full
8 Blade chase 1 >>> 16
9 Random blade chase
10 Blade chase (Paired blades ) Start 1
11 Baled chase (Paired blades) Start 1
12 Blade chase (1/4 blades ) Start 1
13 Blade chase (1/2 blades ) Start 1
14 Blade chase (opposing blades Single ) Start 1
15 Blade chase (opposing blades pairs ) Start 1
16 Blade chase (opposing blades pairs ) Start 1
17 Blade chase (opposing blades pairs ) Start 1
18 Blade chase (opposing blades 1/4 ) Start 1
19 Blade chase (opposing 4 Pixel Rot) Start 1
20 Blade chase (3 Pixel Rotation) Start 1
21 Blade chase TBC
22 Blade chase TBC
23 Blade chase TBC
24 Blade chase TBC
25 Blade chase TBC
26 Blade chase TBC
27 Blade chase TBC
28 Blade chase TBC
29 Blade chase TBC
30 Blade chase TBC
231-255 Reserved
28 28 28
Blade light effects
fade time
0 0 - 255 0 Fade time to XX fade time
29 29 29
Blade light effect
speed
0
0 - 5 Stop No movement
6 - 106
Clockwise chase S>>>>>>>>>F (Strobe fl ash
rate in strobe effects)
107 - 112 Pause No movement hold last position
113 - 213 Counter clockwise chase S>>>>>>>>F
214 - 224 Pause No movement hold last position
225 - 235 Stop No movement
236 - 255 Reserved
30 30
Blade LED Red (1*)
*blade 1 of 16 group
0 0 - 255 8-bit control of Red LED Blade light
