user manual
www.vari-lite.com
VL3600 PROFILE IP
53
TEST
ALL TEST
Runs the self-test of all functions. To stop the test, press [MENU].
PAN/TILT TEST
Runs the self-test of pan/tilt. to stop the test, press [MENU].
TEST CHANNEL
Choose the function you wish to test from the list and touch [ENTER]. The self-test will run. To stop
the test touch [MENU].
ENCODER PAN
Displays the value of the two absolute value encoders for pan. Pan M displays the value of the motor
encoder, and Pan B displays the secondary pan encoder. If pan/tilt movement is enabled, the fixture
will return to previous position after movement.
ENCODER TILT
Displays the value of the two absolute value encoders for tilt. Tilt M displays the value of the motor
encoder, and Tilt B displays the secondary tilt encoder. If pan/tilt movement is enabled, the fixture will
return to previous position after movement.
MANUAL PRESET
PLAYBACK
Power Up Preset
Selects the preset (1 to 20) that will be played back after power up if enabled.
Preset Intensity
Selects the master intensity of a preset being played back (0 to 255).
Priority
Choose Preset if you always want a preset to playback. Choose DMX if you only want a preset to play-
back if there is no DMX present.
Power Up?
Choose Preset On if you want the fixture to playback the preset at power up. Choose Preset O if you
do not want a preset to play.
EDIT
Load Preset
Select from preset 1 to 20 and touch [ENTER]. That preset will be played back.
Edit Settings
Choose the function from the list you wish to edit and touch [ENTER]. Use the [UP]/[DOWN] buttons
to set desired value. Touch [ENTER] to store. Then continue to adjust all function desired. Movement
Shape allows you to select from 3 preset movement eects (Figure 8, Arc, Line) and also set the speed
(slow, medium, fast) and size (small, medium, large). Choose none if no movement eect is desired.
