DMX CHANNEL
PARAMETER DEFAULTS RANGE DMX DESCRIPTION
16-BIT
16-BIT
EXTENDED
(DEFAULT)
23 23
Gobo Wheel 2
Control
0
0 - 255
Used as a control channel for di erent movement
options for
Gobo Wheel 2 (Channel 20)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120
Gobo Shake Quickest Path (Slow to Fast) For
fastest shake set gobo timing to 0
121 - 150
Gobo Shake Normal Path (Slow to Fast) For
fastest shake set gobo timing to 0
151 - 180
Gobo Twist Quickest Path (Slow to Fast) For
fastest twist set gobo timing to 0
181 - 210
Gobo Twist Normal Path (Slow to Fast) For fastest
twist set gobo timing to 0
211 - 255 Reserved Values
0 - 255
8-bit control of VLFX (Gobo Wheel 3).
See Channel 27 for control options.
0 -10 Open - No Gobo
11 -33 Gobo 1 Amoeboid chamber Index
34 -56 Gobo 2 Dichrofusion Index
57 -79 Gobo 3 Concurrent Index
80 -90 Open - No Gobo
24 24 VLFX (Gobo
Wheel 3)
0 91 -113 Gobo 1 Amoeboid chamber Rotate
114 -136 Gobo 2 Dichrofusion Rotate
137 -159 Gobo 3 Concurrent Rotate
160 -170 Open - No Gobo
171 -193 Gobo 1 Amoeboid chamber Rotate Mega
Stepping
194 -216 Gobo 2 Dichrofusion Rotate Mega Stepping
217 -239 Gobo 3 Concurrent Rotate Mega Stepping
240 -255 Open - No Gobo
25 25
VLFX
(Gobo Wheel 3)
Rotate/Index
High Byte 32767
0 - 65535
16-bit control of index and rotation of VLFX (Gobo
wheel 3).
0 - 32756 Rotate Fast to Slow <<<
26 26 Low Byte
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
