DMX CHANNEL
PARAMETER DEFAULTS RANGE DMX DESCRIPTION
16-BIT
16-BIT
EXTENDED
(DEFAULT)
1 1 Intensity High
0 0-65535 16-Bit control of Dimming
2 2 Intensity Low
3 3 Pan High
32767 0-65535 540° Total Pan Rotation
4 4 Pan Low
5 5 Tilt High
32767 0-65535 270° Total Tilt
6 6 Tilt Low
7 7 Focus High
32767 0-65535
Focus control
Default value 50% Focus range
8 8 Focus Low
9 9 Zoom High
32767 0-65535
Zoom control
Default value 50% zoom range
10 10 Zoom Low
11 11 Cyan 0 0 - 255 Cyan Color Control 0-100% saturation
12 12 Yellow 0 0 - 255 Yellow Color Control 0-100% saturation
13 13 Magenta 0 0 - 255 Magenta Color Control 0-100% saturation
14 14 CTO Wheel 0 0 - 255 CTO Color Control 0-100% saturation
15 15
Color
Adjustment
(Color Wheel 2)
0
0 - 255
8-bit control of Color Adjustment (Color Wheel
2) .
0 - 30 Open
31 - 60 CRI Booster
61 - 90 1/2 Minus Green
91-120 1/4 Minus Green
121--180 CTB
181-255 Reserved
16 16
Color Wheel 1
(Color Wheel)
0
0 - 255
8-bit control of Color Wheel.
(spin speed slow to fast from control channel)
OPEN (centered at 0)
0-31 Open
32-63 Red Center - 48
64-95 Dark Blue Center - 80
96-127 Yellow Center - 112
128-159 Kelly Green Center - 144
160-191 Amber Center - 176
192-223 Congo Blue Center - 208
224-255 Open
DMX OPERATION
DMX MAPS
The tables assume a DMX start address of 1. When a dierent starting address is used, this address becomes
channel 1 function and other functions follow in sequence.
