Je bekijkt pagina 19 van 55
uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
19
TAbLE 1. VL2600 PROFILE 16-bIT MODE
DMX
ChaNNeL
ParaMeter DefaULtS raNGe DMX DeSCriPtioN
21
Gobo Wheel 2
(Fixed)
0
0-255
8-bit control of Gobo Wheel for movement options see
channel 22
0 - 5 Open - No Gobo
6 - 10 6-10 Gobo 1 (Leafy Breakup)
11 - 15 11-15 Gobo 2 (Medium Circle)
16 - 20 16-20 Gobo 3 Swirl (Lattice)
21 - 25 21-25 Gobo 4 (Radial Breakup)
26 - 30 26-30 Gobo 5 (Dust)
31 - 35 31-35 Gobo 6 (Neurons)
36 - 40 36-40 Gobo 7 (Grid)
41 - 45 41-45 Gobo 8 (Cross bars)
46 - 255 Reserved
22
Gobo Wheel 2
Control
0
0 - 255 Used as a control channel for di erent movement options for
Gobo Wheel 2 (Channel 21)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120
Gobo Shake Quickest Path (Slow to Fast) For fastest shake
set gobo timing to 0
121 - 150
Gobo Shake Normal Path (Slow to Fast) For fastest shake set
gobo timing to 0
151 - 180 Reserved Values
181 - 210 Reserved Values
211 - 255 Reserved Values
23 Iris 0
0-255 Iris size control
0 - 200 Iris beam size open to closed
201 - 255 Iris pulse slow to fast
24 Frame 1A 0 0 - 255
Controls Framing Shutter 1A from Open (DMX 0) to Full (DMX
255).
25 Frame 1B 0 0 - 255
Controls Framing Shutter 1B from Open (DMX 0) to Full (DMX
255).
26 Frame 2A 0 0 - 255
Controls Framing Shutter 2A from Open (DMX 0) to Full
(DMX 255).
27 Frame 2B 0 0 - 255
Controls Framing Shutter 2B from Open (DMX 0) to Full
(DMX 255).
28 Frame 3A 0 0 - 255
Controls Framing Shutter 3A from Open (DMX 0) to Full
(DMX 255).
29 Frame 3B 0 0 - 255
Controls Framing Shutter 3B from Open (DMX 0) to Full
(DMX 255).
30 Frame 4A 0 0 - 255
Controls Framing Shutter 4A from Open (DMX 0) to Full
(DMX 255).
31 Frame 4B 0 0 - 255
Controls Framing Shutter 4B from Open (DMX 0) to Full
(DMX 255).
32 Frame Rotate 128 0 - 255 Controls Framing Shutter mechanism from +/- 90°
For future use
