Je bekijkt pagina 39 van 55
uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
39
TAbLE 5. VL2600 WASH 16-bIT MODE
DMX
ChaNNeL
ParaMeter DefaULtS raNGe DMX DeSCriPtioN
1 Intensity High
0 0-65535 16 Bit control of Dimming
2 Intensity Low
3 Pan High
32767 0-65535 540° Total Pan Rotation
4 Pan Low
5 Tilt High
32767 0-65535 270° Total Tilt
6 Tilt Low
7 Zoom High
32767 0-65535
Zoom control
8 Zoom Low Default value 50% zoom range
9 Cyan 0 0 - 255 Cyan Color Control 0-100% saturation
10 Yellow 0 0 - 255 Yellow Color Control 0-100% saturation
11 Magenta 0 0 - 255 Magenta Color Control 0-100% saturation
12 CTO 0 0 - 255 CTO Color correction Control 0-100% saturation
13 Color Wheel 0
0 - 255 8-bit control of Color Wheel.
(spin speed slow to fast from control channel)
0 - 15 OPEN (centred at 0)
16 - 47 Color 1 RED (centred at 32)
48 - 79 Color 2 Dark Blue (centred at 64)
80 - 111 Color 3 Yellow (centred at 96)
112 - 143 Color 4 Kelly Green (centred at 128)
144 - 175 Color 5 Amber (centred at 160)
176 - 207 Color 6 Congo Blue (centred at 192)
208 - 240 Color 7 CTB (centred at 224)
241 -255 Open
14
Color Wheel
Control
0
0 - 255
0 - 5 Linear Movement using shortest (quickest) path.
6 - 10 Linear Movement using normal (longest) path.
11 - 15 Wheel Spin CW (Forward)
16 - 20 Wheel Spin STOP
21 - 25 Wheel Spin CCW (Reverse)
26 - 56
Color Shake Quickest Path (Slow to Fast) For fastest shake
set color timing to 0
57 - 87
Color Shake Normal Path (Slow to Fast) For fastest shake set
color timing to 0
88 - 255 Reserved Values
15 Frame 1A 0 0-255 Controls Framing Shutter 1A from Open (0) to Full (255).
16 Frame 1B 0 0 - 255 Controls Framing Shutter 1B from Open (0) to Full (255).
17 Frame 2A 0 0 - 255 Controls Framing Shutter 2A from Open (0) to Full (255).
18 Frame 2B 0 0 - 255 Controls Framing Shutter 2B from Open (0) to Full (255).
19 Frame 3A 0 0 - 255 Controls Framing Shutter 3A from Open (0) to Full (255).
20 Frame 3B 0 0 - 255 Controls Framing Shutter 3B from Open (0) to Full (255).
21 Frame 4A 0 0 - 255 Controls Framing Shutter 4A from Open (0) to Full (255).
22 Frame 4B Controls Framing Shutter 4B fromOpen (0) to Full (255).
23 Frame Rotate 128 0 - 255 Controls Framing Shutter mechanism from +/- 90°
24 Beam softening 0 0-255 Linear control of frost mechanism from out (0) to full in (255)
25 Strobe Speed 0 0 - 255
Controls strobe rate from slowest (0) to fastest (255) 0.5Hz
to 30Hz
