uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
35
TAbLE 4. VL2600 SPOT 16-bIT MODE ENHANCED
DMX
ChaNNeL
ParaMeter DefaULtS raNGe DMX DeSCriPtioN
21
Gobo Wheel 2
continued
0
36 - 40 Gobo 7 (Droplets) Index
41 - 45 Open - No Gobo
46 - 50 Gobo 1 (Dichrofusion) Rotate
51 - 55 Gobo 2 (Alpha Rays) Rotate
56 - 60 Gobo 3 (Circle of holes) Rotate
61 - 65 Gobo 4 (Vertical Bars) Rotate
66 - 70 Gobo 5 (Tribal) Rotate
71 - 75 Gobo 6 (Honeycomb) Rotate
76 - 80 Gobo 7 (Droplets) Rotate
81 - 85 Open - No Gobo
86 - 90 Gobo 1 (Dichrofusion) Rotate with Mega Stepping
91 - 95 Gobo 2 (Alpha Rays) Rotate with Mega Stepping
96 - 100 Gobo 3 (Circle of holes) Rotate with Mega Stepping
101 - 105 Gobo 4 (Vertical Bars) Rotate with Mega Stepping
106 - 110 Gobo 5 (Tribal) Rotate with Mega Stepping
111 - 115 Gobo 6 (Honeycomb) Rotate with Mega Stepping
116 - 120 Gobo 7 (Droplets) Rotate with Mega Stepping
121 - 255 Reserved Values
22
Gobo 2 Rot/Index
High Byte
32767
0 - 65535 16-bit control of index and rotation of gobo wheel 1.
23
Gobo 2 Rot/Index
Low Byte
0 - 32756 Rotate Fast to Slow <<<
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
24
Gobo Wheel 2
Control
0
0 - 255
Used as a control channel for di erent movement options for
Gobo Wheel 2 (Channel 21).
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin Reverse (Slow to Fast)
91 - 120
Gobo Shake Quickest Path (Slow to Fast) For fastest shake
set gobo timing to 0
121 - 150
Gobo Shake Normal Path (Slow to Fast) For fastest shake set
gobo timing to 0
151 - 180
Gobo Twist Quickest Path (Slow to Fast) For fastest twist set
gobo timing to 0
181 - 210
Gobo Twist Normal Path (Slow to Fast) For fastest twist set
gobo timing to 0
211 - 255 Reserved Values
25
Gobo Wheel 3
(Fixed)
0
0-255
8-bit control of Gobo Wheel 3. for movement options see
channel 26
0 - 5 Open - No Gobo
6 - 10 6-10 Gobo 1 (Leafy Breakup)
11 - 15 11-15 Gobo 2 (Medium Circle)
16 - 20 16-20 Gobo 3 Swirl (Lattice)
