uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
29
TAbLE 3. VL2600 SPOT 16-bIT MODE
DMX
ChaNNeL
ParaMeter DefaULtS raNGe DMX DeSCriPtioN
21 Gobo Wheel 2 0
0-255
8-bit control of Gobo Wheel for movement options see
channel 24
0 - 5 Open - No Gobo
6 - 10 Gobo 1 (Dichrofusion) Index
11 - 15 Gobo 2 (Alpha Rays) Index
16 - 20 Gobo 3 (Circle of holes) Index
21 - 25 Gobo 4 (Vertical Bars) Index
26 - 30 Gobo 5 (Tribal) Index
31 - 35 Gobo 6 (Honeycomb) Index
36 - 40 Gobo 7 (Droplets) Index
41 - 45 Open - No Gobo
46 - 50 Gobo 1 (Dichrofusion) Rotate
51 - 55 Gobo 2 (Alpha Rays) Rotate
56 - 60 Gobo 3 (Circle of holes) Rotate
61 - 65 Gobo 4 (Vertical Bars) Rotate
66 - 70 Gobo 5 (Tribal) Rotate
71 - 75 Gobo 6 (Honeycomb) Rotate
76 - 80 Gobo 7 (Droplets) Rotate
81 - 85 Open - No Gobo
86 - 90 Gobo 1 (Dichrofusion) Rotate with Mega Stepping
91 - 95 Gobo 2 (Alpha Rays) Rotate with Mega Stepping
96 - 100 Gobo 3 (Circle of holes) Rotate with Mega Stepping
101 - 105 Gobo 4 (Vertical Bars) Rotate with Mega Stepping
106 - 110 Gobo 5 (Tribal) Rotate with Mega Stepping
111 - 115 Gobo 6 (Honeycomb) Rotate with Mega Stepping
116 - 120 Gobo 7 (Droplets) Rotate with Mega Stepping
121 - 255 Reserved Values
22
Gobo 2 Rot /
Index High Byte
32767
0 - 65535 16-bit control of index and rotation of gobo wheel 1.
23
Gobo 2 Rot /
Index Low Byte
0 - 32756 Rotate Fast to Slow <<<
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
