TAbLE 1. VL2600 PROFILE 16-bIT MODE
DMX
ChaNNeL
ParaMeter DefaULtS raNGe DMX DeSCriPtioN
1 Intensity High
0 0-65535 16 Bit control of Dimming
2 Intensity Low
3 Pan High
32767 0-65535 540° Total Pan Rotation
4 Pan Low
5 Tilt High
32767 0-65535 270° Total Tilt
6 Tilt Low
7 Focus High
32767 0-65535
Focus control
Default value 50% Focus range
8 Focus Low
9 Zoom High
32767 0-65535
Zoom control
Default value 50% zoom range
10 Zoom Low
11 Cyan 0 0 - 255 Cyan Color Control 0-100% saturation
12 Yellow 0 0 - 255 Yellow Color Control 0-100% saturation
13 Magenta 0 0 - 255 Magenta Color Control 0-100% saturation
14 CTO 0 0 - 255 CTO Color correction Control 0-100% saturation
15 Color Wheel 0
0 - 255
8-bit control of Color Wheel.
(spin speed slow to fast from control channel)
0 - 15 OPEN (centred at 0)
16 - 47 Color 1 RED (centred at 32)
48 - 79 Color 2 Dark Blue (centred at 64)
80 - 111 Color 3 Yellow (centred at 96)
112 - 143 Color 4 Kelly Green (centred at 128)
144 - 175 Color 5 Amber (centred at 160)
176 - 207 Color 6 Congo Blue (centred at 192)
208 - 240 Color 7 CTB (centred at 224)
241 -255 Open
16
Color Wheel
Control
0
0 - 255
0 - 5 Linear Movement using shortest (quickest) path.
6 - 10 Linear Movement using normal (longest) path.
11 - 15 Wheel Spin CW (Forward)
16 - 20 Wheel Spin STOP
21 - 25 Wheel Spin CCW (Reverse)
26 - 56
Color Shake Quickest Path (Slow to Fast) For fastest shake
set color timing to 0
57 - 87
Color Shake Normal Path (Slow to Fast) For fastest shake set
color timing to 0
88 - 255 Reserved Values
17 Gobo Wheel 1 0
0 - 255 8-bit control of Gobo Wheel 1. See Channel 20 for control
0 - 5 Open - No Gobo
6 - 10 Gobo 1 (Night Sky) Index
11 - 15 Gobo 2 (Circle of Ovals) Index
16 - 20 Gobo 3 (Bricked Out) Index
21 - 25 Gobo 4 (Punchcard) Index
26 - 30 Gobo 5 (Swirl) Index
31 - 35 Gobo 6 (Honeycomb Reverse) Index
36 - 40 Gobo 7 (On the Rock) Index
41 - 45 Open - No Gobo
