SL NITRO 510C LED STROBE Luminaire Operational Specifications 53
SL NITRO 510C LED STROBE Luminaire
Installation & User’s Manual
Sh wline
TECHNICAL SPECIFICATIONS
1. SL NITRO 510C LED STROBE Luminaire Operational Specifications
Source: High Intensity RGB & W LED Array (x264 Red, Green, Blue / x 264 White)
Beam Angle: 120 Degrees
Light Output: > 50,000 lumens
Strobe Operation: Variable Strobe: 0 to 650 ms / Strobe Rate: 0 to 30 flashes per second
Color Temperature: 6500K
Input Voltage (AC): 100V to 240V (+/- 10%, auto-ranging)
Current (AC): 3.6 Amps (100V) / 1.50 Amps (240V)
Frequency: 50/60Hz
Control Protocols: DMX512 (1990) / DMX512A (RDM) / On-Board Menu
Ambient Temperature: -20 to 40 Degrees C (-4 to 104 Degrees F)
Humidity: 5%-95% Non condensing
Cooling: Forced Air Cooling
Weight: 17.6 lbs (8 kg) - Luminaire only (no accessories)
Housing: Die Cast Aluminium with Powder Coating
Compliance: cETLus marked (North American models) / CE Marked (International models) / cTick
IP Rating: IP20
2. SL NITRO 510C LED STROBE Luminaire Dimensions
390 mm / 15.35 in.
186.5 mm
/ 7.34 in.
130 mm /
5.12 in.
263 mm / 10.35 in.
186.5 mm / 7.34 in.
142.5 mm /
5.61 in.
13 mm / 0.52 in.
332.6 mm / 13.10 in.
80.0 mm /
3.15 in.
103 mm /
4.06 in.
