PHT-800#
12
Troubleshooting
Troubleshooting Procedures
The Powered Hand Truck is a quality product that is designed and manufactured to provide
prolonged service under normal operating conditions. If troubleshooting is required, it
should be performed only by qualified personnel who are familiar with the equipment.
Troubleshooting procedures are shown in Table 2.
Table 2: Troubleshooting Procedures
Problem Possible Cause Corrective Action
Drum Truck will not run. Motor not getting power Ensure key switch is on. Check battery gauge, if
battery charge is low, connect charger to appropriate
power source.
Blown Fuse Check fuse located on control panel. Replace if blown.
Failed switch or wiring Check indicator LED on control panel. If ashing, see
Table 5 on following page for code information.
Failed Electric Motor Check indicator LED on control panel. If ashing, see
Table 5 on following page for code information.
Hand Brake not stopping
truck.
Brake bands not tensioned
properly
See page 10 for instructions on how to properly adjust
brake tension.
Drum truck is overloaded Remove overload; 800 lbs maximum capacity.
Batteries not charging.
Batteries not hooked up
Check to see that the batteries are both connected.
Charger setting incorrect
Plug the battery charger in and check to see if the
charger is set to 24V and AMG. If it is not unplug the
batteries from the charger and use the "Voltage" and
"Battery" buttons on the charger to select the correct
settings. Re-connect batteries when done .
Blown charging fuse
Check charger fuse located inside control box.
Replace if blown.
Z41322A7
Battery Gauge not
displaying correctly.
Battery Gauge needs to be reset
Turn key switch "ON" and leave on for 15-20
minutes or until the battery gauge resets and
displays correctly
