Je bekijkt pagina 12 van 14
NOTE:
SEE SHEET NUMBER 9 FOR CYLINDER AND
HAND PUMP SEAL KITS.
ITEM NO.
PART NUMBER
DESCRIPTION
Default/QTY.
1
F64985A5
RAPTOR WLDMNT-MAST
1
2
F64982A8
RAPTOR ASSY-ATTMT
1
3
F61059A3
RAPTOR RS WLDMNT-ATTMT
1
4
F62980A9
RATCHET ASSY-2.0X53.00 7000
2
5
Z40469A9
DECAL-LOAD CAP 800
1
6
Z40457A3
DECAL-CAUTION STRADDLE LIFT
1
7
Z30538A8
CSTR-8X2 SWL PHN TLB
1
8
Z30552A4
WHL-6 x 2 PNH
2
9
Z10585A9
S-HHC 1/2-13X3-1/4
2
10
Z10393A3
NUT-LOCK 1/2-13
2
11
Z10113A2
S-HHC 1/4-20X1-1/4
2
12
Z10043A7
NUT-NYL NE 1/4-20
2
13
Z20734A0
BREATHER 4 SAE SINTERED--COMES WITH CYLINDERS
1
14
Z10072A1
PIN-SPG 1/4X1-1/2
1
15
Z20615A7
FTG STR 6400-4-4-O
1
16
Z20736A8
HOSE-20.00/613
2
17
Z10241A7
BOLT-U 5/16-18 X 2-1/2
1
18
F52067A6
PIN-CLEVIS 1.00X2.375 (KANBAN)
1
19
Z20704A0
FTG 90 6500-4-4 SWL
1
20
Z10045A5
NUT-NYL NE 5/16-18
2
21
Z10200A6
WASHER-1/4 FLAT USS
4
22
Z10187A3
S-SHC 1/4-20X3/4
4
23
Z10035A7
NUT-HEX KEPS 1/4-20
4
24
Z10020A4
NUT-HEX FULL 1/2-13
2
25
Z10123A0
S-HHC 5/16-18X1
2
26
Z10036A6
NUT-HEX KEPS 5/16-18
2
27
Z30573A3
PIN-CLEVIS 1/2 X 3
2
28
Z10064A1
PIN-HITCH CLIP #16 1/8 X 1.44
2
29
Z10525A3
BUSH-SPAN 3/4X1/2x2-7/16
2
30
Z50085A2
GRIP-HDL 1-1/4" BLK
2
31
Z20755A8
CYL ASSY/RAPTOR
1
32
F63091A3
SPROCKET ASSY-50C18 BRG 1.01 (purchased)
1
33
Z10121A2
S-HHC 5/16-18X1/2
2
34
F63858RB
CHAIN-RLR ASSY LONG
1
35
Z40473A3
TAG/SERIAL NUMBER/PRINT 2 COLORS
1
36
Z41156A5
LABEL-VALLEYCRAFT PAPER
1
37
Z10134A7
S-HHC 3/8-16X1-1/2
4
38
Z20895A0
HAND PUMP w/HANDLE
1
39
Z10202A4
WASHER-3/8 FLAT SAE
4
40
Z10500A7
NUT-HEX KEPS 3/8-16
4
41
F57524
MOUNTING PLATE
1
12
RAPTOR-RATCHET STRAP
