u
Move the bracket so it sits flush on the side wall of the
cabinet recess. Tighten all the screws securely.
Fig. 46
u
Break off the stop from the bracket on the handle side
and dispose of it.
14.3 Inserting the covers and height
adjuster
Fig. 47
u
Put on the covers.
Fig. 48
u
Slide the panel so that it sits flush with the side of the
cabinet wall.
Fig. 49
u
The sealing strip is magnetic. Position the sealing strip
below the top cover and press it in. If necessary, shorten
the sealing strip to the required length with a sharp pair
of scissors.
Fig. 50
The supplied height adjuster is used to optimise noise.
Both parts of the height adjuster are included in the
accessory kit.
u
To stabilise the appliance at the back underneath: Fit the
handle onto the rail of the height adjuster and push the
rail into the appliance base. Remove the handle and do
the same with the second rail.
14.4 Mounting the front of the cabinet
Fig. 51
u
Close the door and check the preset of 8 mm from
the upper edge of the appliance door to the crosspiece
support
Installing the appliance in the recess
62 * Depending on model and options
