TEST
• Turn the TIME knob anti-clockwise on the minimum
(10s). Turn the LUX knob clockwise on the maximum
(sun).
• Switch on the power; the sensor and its connect-
ed lamp will have no signal at the beginning. Aer
Warm-up 30sec, the sensor can start work .If the sen-
sor receives the induction signal, the lamp will turn on.
While there is no another induction signal any more,
the load should stop working within 10sec±3sec and
the lamp would turn o.
NOTE: when testing in daylight, please turn LUX knob to (SUN) position, otherwise the sensor lamp
will not work!
• Turn LUX knob anti-clockwise on the minimum (3). If the ambient light is more than 3LUX, the
sensor would not work and the lamp stop working too. If the ambient light is less than 3LUX
(darkness), the sensor would work. Under no induction signal condition, the sensor should stop
working within 10sec±3sec.
SENSOR DIAGRAM
CONNECTION-WIRE DIAGRAM
Height of installation: 1.8-2.5m Detection Distance: Max12m
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
SUPPORT@VTACEXPORTS.COM V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT,
SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
