- 17 -
3.8 WIFI Connec�on
3.7 Earth Connec�on(mandatory)
Ground cable shall be connected to ground plate on grid side this prevents electric shock. if the
original protec�ve conductor fails.
For the configura�on of Wi-Fi Plug, please refer to illustra�ons of the Wi-Fi Plug. The Wi-Fi Plug
is not a standard configura�on, it's op�onal.
RS485B
Note:
In final installa�on,breaker cer�fied according to IEC 60947-1 and IEC 60947-2
shall be installed with the equipment.
ON
1 2
1
230V/2T
5 6 7 8 9 10
2
3
A B
4
GND
1+COM 2+
L N
L N PE L N PE
L N PE
Grid
AC
Breaker
L
N
System connec�on diagram for the Eastron meter
Output
RS 485 GND
Input
Pic 7.1 EASTRON meter
EASTRON SDM230
1
230V/2T
5 6 7 8 9 10
2
3
A B
4
GND
1+COM 2+
5
3
6
7
GNDA B
L
N
L
N
1
2 4
RS485B
RS485A
Load
GEN
Grid
Inverter
RS 485/
METER
parallel_1 parallel_2
BMS 485/
CAN
DRMs
ON
1 2
