Network Settings
User Guide 77
4. Select On or Off of Always Allow ICMP.
When Always Allow ICMP is set to On, ICMP function takes precedence even if IP
Filter (IPv6) is set to On. On the other hand, when setting to Off, the IP filter settings
are applied as they are.
5. Click Settings button. The IP Filters (IPv6) page opens.This section includes the
following items for configuration.
Network Interface
Select Wired Network, Wi-Fi and Wi-Fi Direct as the available network for IP Filter
(IPv6).
IP Address(IPv6)
Specifies the IP addresses to which access is granted. When there are no entries,
access is allowed to all. The number of addresses that can be specified depends on
the IPv6 network address along with the prefix length setting. IPv6 address filtering:
To filter a single IPv6 address: Enter the desired IPv6 address, along with a prefix
length of 128.
Prefix Length
Specifies the IPv6 prefix length. It can be a decimal value between 0 and 128.
Note: When the IPv6 address is ":: 1", "128" cannot be set for the Prefix length.
Protocols
Specifies the protocol by which an access is granted. You can specify multiple pro-
tocols.
Note: ThinPrint appears only when an optional ThinPrint is activated.
6. Click Submit button.
Logical printers
This page allows you to configure the Logical Printers. This machine can be used as a
virtual printer for converting ASCII print data to PostScript data or for adding and/or
replacing a character strings (commands) at the beginning or end of job data. Up to four
logical printers can be set.
Logical Printer is used with one of the following print protocols: FTP, LPR, IPP, IPPS,
SMB and RAW. If no port is specified for printing, the default port used will be Logical
Printer 1 (LP1), port 9100.
1. Click TCP/IP under Network Settings on the navigation menu. The Network Settings
: TCP/IP page opens.
2. Click Settings button. The Logical Printers page opens.This section includes the
following items for configuration
TCP/IP Port Number
Specifies the port number for the logical printer as well as the TCP raw port number
(9100, etc.). Conversion is applied to data that is input to the specified raw port in
accordance with the selected logical printer. This port is invalid if it is given a port
number that is the same as that of an already specified port (For example, FTP or
LPD).
