Function Settings
62 Embedded Web Server
3. FAX Number: Displays when you select FAX Number as Rule Type. After
selecting rule, enter the fax number.
4. Reception Port: Displays when you select Reception Port as Rule Type. Select
Port 1 or Port 2.
5. i-FAX Address: Displays when you select i-FAX Address as Rule Type. After
selecting rule, enter the i-FAX address.
Schedule
Configure the schedule for the specified rule.
1. Schedule: Select All Day or Preset Time.
2. Start Time, End Time: You can configure the setting when you select Preset Time
as Schedule. Specify the time table from the drop-down list.
File Name
Configure the file name created when forwarding.
1. File Name: Enter the file name.
2. Additional Information: Select the additional information on the file name from
the drop-down list.
Forward Settings
Configure the forward destination.Select the destination on the list, and then click
the Delete icon.
1. Forwarding: Select On and click the desired address button to specify the
forwarding destination.
2. Address Book: Click Address Book button to open the Addresses page. Select
the desired Address Book and click Submit button.
3. E-mail: Click E-mail button to open the E-mail page. Enter E-mail Address and E-
mail Address (Confirmation), and then click Submit button.
4. Folder: Click Folder button to open the Folder page.
Protocol: Select SMB or FTP.
Host Name
: Enter the host name. If you use the host name, you must first specify
the DNS
server information.
Port Number: E
nter the port number from 1 to 65535.
Path: Enter the path of the folder.
Login User Name: Enter the login user name.
Login Password: Enter the login password.
Connection Test: Click Test button to confirm the connection to the folder.
5. FAX: Click FAX button to open the FAX page.
FAX Number: Enter the fax number.
Sub Address: Enter the sub address.
Password: Enter the password for the sub address.
TX Start Speed: Select 33600 bps, 14400 bps, or 9600 bps.
ECM: Select On to use ECM communication.
Encryption: Select Off, Key 1 to Key 20. You can select Key 1 to Key 20 when
registering the encryption key in FAX Settings page under Function Settings.
Encryption Box: Select On to use the encryption box. You can configure this set-
ting when the encryption key is selected on Encryption.
Encryption Box No.: Enter the box number (4 digits). You can configure this set-
ting when the encryption key is selected on Encryption and Encryption Box is
set to On.
6. i-FAX: Click i-FAX button to open the i-FAX page.
i-FAX Address: Enter the i-FAX address.
Via Server: Select On to send i-FAX via server.
Connection Mode: Select Simple or Full.
Resolution: Select 200 x 100 dpi, 200 x 200 dpi, 200 x 400 dpi, 400 x 400 dpi or
600 x 600 dpi.
