Network Settings
User Guide 85
IEEE802.1X
Effective Encryption: Select a method of encryption from EAP-TLS, EAP-TTLS,
EAP-FAST and PEAP(EAP-MS-CHAPv2) on the drop-down list.
Tunneled Authentication Protocol: This protocol is activated when EAP-TTLS
has been selected for encryption. Select a method of authentication from
MSCHAPV2, MSCHAP, CHAP, and PAP on the drop-down list.
Login User Name: Enter the name of the user to access the machine. The
IEEE802.1X client certificate of this user must be valid.
Password: This protocol is activated when EAP-TTLS, EAP-FAST, or
PEAP(EAP-MS-CHAPv2) has been selected for encryption. Enter the password.
Common Name: This protocol is activated when EAP-TTLS, EAP-FAST, or
PEAP(EAP-MS-CHAPv2) has been selected for encryption. Specifies the com-
mon name of the server certificate if the server is required to be authenticated.
Match Rule of Common Name: This protocol is activated when EAP-TTLS, EAP-
FAST, or PEAP(EAP-MS-CHAPv2) has been selected for encryption. When the
server certificate is verified, the common name specified under Common Name is
compared with the common name on the server certificate. This item allows you to
specify whether the common names are considered to be matched if they exactly
or partially match.
Expiration Verification: When this option is enabled, the expiration of the server
certificate is verified at communicating. If the certificate is expired, communication
will fail. When it is disabled, the expiration will not be verified.
IEEE802.1X Client Certificate: The current status is shown in IEEE802.1X Client
Certificate. To make advanced settings, click Settings button and select a device
certificate. Click Submit button to finalize settings. Configure the device certificate
on the Security Settings: Certificates page.
Certificate Status
Root Certificate 1 (to 5), IEEE802.1X Client Certificate: The content of the certif-
icate is shown. Make settings for the Root Certificate on the Security Settings:
Certificates page.
9. LLTD: LLTD is a protocol that provides network topology discovery and quality of
service diagnostics. To enable the LLTD protocol, turn this item On.
Available Network: S
elect W
ired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for LLTD protocol.
10.REST: REST is an architecture for the web application suitable for the multiple
software linkage in the distributed network system. To enables the REST protocol,
turn this item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for REST protocol.
Port Number: Enter the port number. Typically, this should be 9080.
11. REST over TLS: A certificate can be added for communication using the REST
protocol. To enable the REST over TLS, turn this item On. To enable this protocol,
select On on TLS of the Network Security Settings page.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for REST over TLS.
Port Number: Enter the port number. Typically, this should be 9081.
REST over TLS Certificate: The status of REST over TLS Certificate is shown.
To make advanced settings, click Settings button and select a certificate.
12.VNC (RFB): VNC (RFB) is set when starting up a VNC Viewer (E.g. RealVNC),
and using the Remote Operation. To enables the VNC (RFB) protocol, turn this
item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for VNC (RFB) protocol.
Port Number: Enter the port number. Typically, this should be 9062.
13.VNC (RFB) over TLS: VNC (RFB) over TLS is set when starting up a VNC Viewer
(E.g. RealVNC), and using the Remote Operation protected by TLS. To enable the
