Network Settings
User Guide 81
1. Click Protocol under Network Settings on the navigation menu. The Network
Settings : Protocol page opens.
2. This section includes the following items for configuration.
Print Protocols
Configure the protocols used for printing. This section includes the following items
for configuration:
1. SMB Server Protocol: SMB Server Protocol allows you to share printers and files
over a network. When setting to On, you can also set SMBv1.
Workgroup: A name for grouping multiple computers in order to use functions
such as file sharing. You can also change it.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for SMB server protocol.
SMBv1: Set to On to share files and printers using the SMBv1 protocol.
2. LPD: To enables the LDAP protocol, turn this item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for LPD protocol.
3. FTP Server (Reception): FTP is a communications protocol for transmitting files
over a Network. To enables the FTP protocol, turn this item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for FTP protocol.
4. IPP: IPP is a protocol which performs transmission and reception of printing data
and configuration of machines through TCP/IP networks including the Internet. To
enables the IPP protocol, turn this item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for IPP protocol.
Port Number: Enter the port number. Typically, this should be 631.(e.g. http://(IP
address):631/printers/lp1)
5. IPP over TLS: A certificate can be added for communication using the IPP
protocol. To enable the IPP protocol, turn this item On. To enable this protocol,
select On on TLS of the Security Settings : Network Security page.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for IPP over TLS.
Port Number: Enter the port number. Typically, this should be
443.
The status of
IPP over TLS Certificate is sh
own. To make advanced settings, click Settings
button and select a certificate. Click Submit button to finalize settings.
Configure the device certificate on the Security Settings : Certificates page. This
Certificate can be used in common with IPP over TLS and HTTPS.
6. IPP Authentication: When selecting On, the device performs user authentication
at printing to avoid unauthorized use. To enable this item, select Local
Authentication or Network Authentication as Authentication on the
Management Settings : Authentication page and restart the device. Turn this
item On and enter Default User Name.
7. Raw: RAW employs another method of printing over the network like LPR.
Typically, RAW uses port 9100 to remotely administer the printer via using SNMP
or MIB. To enables the RAW protocol, turn this item On.
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for Raw protocol.
8. ThinPrint: Configure this setting whether to use the ThinPrint. Turn this item On
Available Network: Select Wired Network, Wi-Fi and Wi-Fi Direct as the avail-
able network for ThinPrint.
Port Number: When you set ThinPrint to On, enter the port number. Typically,
this should be 4000. To use ThinPrint over TLS, select On on TLS of the Secu-
rity Settings : Network Security page. Click Settings button to select the Device
Certificate. Click Submit button to determine the setting.
Note: ThinPrint appears only when an optional ThinPrint is activated.
