Network Settings
78 Embedded Web Server
Bi-directional Printing
Bi-directional Printing can be set to On or Off when printing to the TCP/IP RAW
port. When Bi-directional Printing is Off, all Send data is discarded.
In order to have the data that is received from the printer returned to the client when
printing with PostScript, PJL and other such commands, it is necessary to set Bi-
directional Printing is On.
Start of Job String
Specifies the character string sent to the printer after output, directly to the output
port (lp port). This character string is used when it is necessary to transmit a control
code before the print data is sent.
End of Job String
Specifies the character string sent to the printer after output, directly to the output
port (lp port). This character string is used when it is necessary to transmit a control
code after the print data is sent.
3. Click Submit button.
IPSec Settings
1. Click TCP/IP under Network Settings on the navigation menu. The Network Settings
: TCP/IP page opens.
This section allows you to set access restrictions for IPSec protocol-based
communication.
Specifies whether or not to enable the IPSec protocol. Select On to use the IPv6
protocol. Select Off when encryption is not used.
2. This section includes the following items for configuration.
Expiration Verification
When this option is enabled, the expiration of the server certificate is verified at
communicating. If found expired, communication will fail. When it is disabled, the
expiration will not be verified.
FIPS140-2 Compliant
When selecting On, you can communicate using encrypted module which is compli-
ant with FIPS 140-2.
Note: When activating optional Data Security Kit 10, you can communicate using
encrypted module which is same level as FIPS 140-2.
Restriction
Specifies the default policy for non-IPSec packets. Select Allow to allow communi-
cation with all hosts and networks including those not permitted by the rules. Select
Deny to allow communication only with the hosts and networks permitted by the
rules. Allowed means normal traffic (not defined by the IPSec rules) will be allowed
to reach the device. Denied means only IPSec traffic (as defined by the IPSec
rules) will be allowed to reach the device and all other traffic (not defined by the
IPSec rules) will be denied to reach the device.
