Function Settings
54 Embedded Web Server
the text. When Reduction Override is selected, the document will be printed on
one sheet whenever possible.
5. Receive Data/Time: Selects On or Off whether to print the reception information
such as the received date, the received time, the transmitting party's information
and the number of transmitted pages on the top of the received documents.
6. Duplex Printing: Specifies whether or not to use the Duplex mode.
7. 2 in 1 Printing: Enables or disables 2 in1 reception.
8. Batch Print: Selects whether or not perform batch print of the received
documents.
4. Click Submit button.
Fax Settings
1. Click FAX/i-FAX under Function Settings on the navigation menu. The Function
Settings : FAX/i-FAX page opens.
2. You can configure settings for General. Make the following settings:
1. Local FAX Number: Specifies your FAX system number.
2. Local FAX ID: Specifies your FAX ID.
3. Speaker Volume: Sets the volume of the internal speaker that allows you to listen
to the other party or to verify the conditions on the telephone line when the On-
Hook key was pressed. Select the speaker volume from 0 (Mute) to 5
(Maximum).
4. Monitor Volume: Sets the volume of the internal speaker that allows you to verify
the FAX tones during FAX communication. Select the speaker volume from 0
(Mute) to 5 (Maximum).
3. You can configure settings for Transmission. Make the following settings:
1. Dialing Mode: According to the type of telephone line you are contracted with,
select Tone (DTMF), Pulse (10PPS), or Pulse (20PPS).
2. TX Start Speed: Selects the speed rate at starting transmission from 33600bps,
14400bps, and 9600bps. Once communication is established, the speed rate that
is slower than the other is employed.
3. ECM TX: Turns error correction mode on which corrects errors that may happen
during communication. To let the ECM feature to take effect, error correction mode
must be enabled on both parties in prior.
4. You can configure settings for Reception. Make the following settings:
1. FAX Receive: Selects the FAX reception mode. The choices are Auto (Normal,
FAX/Tel, TAD or DRD) or Manual. (The selectable option is different depending on
the destination.)
2. Number of Rings (Normal): Specifies the number of rings when FAX Receive is
Auto (Normal). The range is 1 to 15.
3. Number of Rings (FAX/Tel): Specifies the number of rings when FAX Receive is
Auto (FAX/Tel). The range is 0 to 15.
4. Number of Rings (TAD): Specifies the number of rings when FAX Receive is
Auto (TAD). The range is 1 to 15.
5. Remote Switching Dial Number: Specifies the FAX remote switching dial
number. The range is 00 to 99. Remote switching allows you to initiate FAX
reception from a telephone connected to the FAX system.
6. Encryption Key No.: Sets the encryption key number used for encrypted
communication.
7. RX Start Speed: Selects the speed rate at starting reception from 33600 bps,
14400 bps, and 9600 bps. Once communication is established, the speed rate that
is slower than the other is employed.
