LSS−100P Installation & Operation Manual
v160318 22
lss100.sys.script_wait|30
Causes a script to wait the
specified number of seconds
before executing the next line.
Waits between captures keeps
the measurement capture
synchronized with the test
content.
Figure 18 - LSS-100P TCP Commands
TCP_Send Command Usage
The tcp_send command allows a user to have the LSS relay TCP strings to other devices by having the
command embedded within a script. The usage of this command is shown below:
lss100.sys.tcp_send_string|address|port|string
Example:
lss100.sys.tcp_send_string|192.168.1.123|10001|qli32.sys.test.speaker_test 15 1\r
The example command tells a Lexicon QLi32 (located at 192.168.1.123, port 10001) to put pink noise on
each speaker in sequence for 15 seconds (looping once). An LSS-100P script can capture the SPL of each
of the speakers.
Allowed escape codes are:
\\ = backslash
\t = tab
\n = newline
\r = carriage return
\a = alarm (bell)
\f = form feed
\v = vertical tab
\b = backspace
CP850 Control
The LSS-100P is capable of integration with a Dolby® CP850 Cinema Processor to check individual
speakers in a Dolby ATMOS® configuration. To unlock access to TCP commands that control the Dolby©
CP850 Cinema Processor contact USL for a license key.
The command below causes the LSS-100P to send a command to the CP850 at the specified address
(192.168.1.146 in the example) to go into a test mode. In this mode, the CP850 sends pink noise to each
speaker individually. By timing how much time is spent on each speaker, a custom test script can be
written so the LSS-100P captures the SPL on each speaker.
lss100.sys.cp850_test_start|192.168.1.146
The command below causes the LSS-100P to send a command to the CP850 stopping the test. The IP
address specified in the last cp850_test_start is used.
lss100.sys.cp_850_test_stop
