10
TD-001576-01-A
Audio Settings
The CMS supports up to 24 channels of AES audio output via the front panel RJ connectors and up to 64 channels of audio when
used with Q-SYS. All CMS include DTS:X™ immersive audio rendering up to 16 channels and 64 channels rendering is available with
an additional software license. Audio configuration can be accessed by logging in to the CMS-5000 UI application with installer or
administrator privileges and navigating to System->Audio.
Video Alignment Delay
To align audio with video playback, use the audio delay slider. Up to 200 ms of delay can be set in either direction. If audio is lagging the
video, set a negative delay. If audio is preceding the video, set a positive delay.
Q-LAN Audio Output Enable
Q-LAN output can be enabled or disabled. If disabled, no audio streams will be output to the Q-SYS network though you can still control
the CMS via the Q-SYS CMS component in the Q-SYS design.
AES Channel Assignments
The default channel assignments for AES output channels 1-16 are based on the standard as called out by ISDCF Doc4 – 16 Channel
Audio Packaging Guide as shown below. Any channel can be reassigned to any AES output as needed. If that output had already been
assigned to a different channel, the channels will swap output assignments.
— Table 3 — AES CH 1-16 Default Audio Channel Mapping and Pinout
Source DTSX Source
(VBAP Ch #)
Output Channel AES Pair/Channel RJ / Pin
L 0 1 Pair1 / Ch1 AES1-8 / 1
R 1 2 Pair1 / Ch2 AES1-8 / 2
C 2 3 Pair2 / Ch1 AES1-8 / 3
LFE 3 4 Pair2 / Ch2 AES1-8 / 6
LSS 4 5 Pair3 / Ch1 AES1-8 / 4
RSS 5 6 Pair3 / Ch2 AES1-8 / 5
HI – 7 Pair4 / Ch1 AES1-8 / 7
VI – 8 Pair4 / Ch2 AES1-8 / 8
LC 6 9 Pair5 / Ch1 AES9-16 / 1
RC 7 10 Pair5 / Ch2 AES9-16 / 2
LRS 8 11 Pair6 / Ch1 AES9-16 / 3
RRS 9 12 Pair6 / Ch2 AES9-16 / 6
SYNC1 – 13 Pair7 / Ch1 AES9-16 / 4
SYNC2 – 14 Pair7 / Ch2 AES9-16 / 5
CH15 – 15 Pair8 / Ch1 AES9-16 / 7
CH16 – 16 Pair8 / Ch2 AES9-16 / 8
CH17 10 17 Pair9 / Ch1 AUX1-8 / 1
CH18 11 18 Pair9 / Ch2 AUX1-8 / 2
CH19 12 19 Pair10 / Ch1 AUX1-8 / 3
CH20 13 20 Pair10 / Ch2 AUX1-8 / 6
CH21 14 21 Pair11 / Ch1 AUX1-8 / 4
CH22 15 22 Pair11 / Ch2 AUX1-8 / 5
CH23 16 23 Pair12 / Ch1 AUX1-8 / 7
CH24 17 24 Pair12 / Ch2 AUX1-8 / 8
