Communication socket

Power board comes with:

■ 1 CANBUS socket to communicate with the control board (P11)

■ 2 CANBUS socket to communicate with another power board and with a CANBUS-ETHERNET (P12, P13)

■ 3 MODBUS doors to communicate with accessory power board (P8, P9, P10)

■ Power supply

PARAMETER NOMINAL VALUE MINIMUM VALUE MAXIMUM VALUE

NETWORK VOLTAGE SUPPLY 230 V

AC

180 V

AC

270 V

AC

NETWORK FREQUENCY SUPPLY - 50 Hz 60 Hz

PRIMARY TRANSFORMER

VOLTAGE

230 V

AC

180 V

AC

270 V

AC

SECONDARY TRANSFORMER 1

VOLTAGE

21 V ~ - -

SECONDARY TRANSFORMER 2

VOLTAGE

12 V ~ - -

SECONDARY TRANSFORMER 1

CURRENT

4.2 A - -

SECONDARY TRANSFORMER 2

CURRENT

83 mA - -

Socket table

SoCKeT

SOCKET TYPE N° PiN LABEL DESCRIPTION

P1

INARLOCK 6P 2F

(White)

1 N

Board power supply (neutral)

2 N_F

3 L_F

Transformer power supply (phase)

4 L Board power supply (phase)

5 COND Capacitor for the motor startup

6 COND Capacitor for the motor startup

P2

INARLOCK 5P 1F

(Black)

1 N Neutral

2 RW

Motor power supply -counterclock wise spinning

3 FW Motor power supply -clock wise spinning

4 F Phase 230 Vac

5 TM Motor thermal protection input

P3

INARLOCK 3P 1F

(Black)

1

RES1 Braking element 1

2

RES2 Braking element 2

3

P4

INARLOCK 6P 1F

(White)

1 PD

Detergent pump phase

2 N

Detergent pump neutral

3 EL1

Water solenoid valve EL1 phase

4 N

Water solenoid valve EL1 neutral

5 VENT

DRY.Maxi phase

6 N

DRY.Maxi neutral

Transformer power supply (filtered neutral)

21
