Fuse list

FUSE

NOMINAL

CURRENT

NOMINAL

VOLTAGE

SPEED OF

INTERVENTION

PROTECTED CIRCUIT

F2 2A 250V Fast (F) Primary transformer (TR60 230V-12V 60VA)

F3 2A 250V Fast (F) Detergent pump (PD output on P4 socket)

F4 4A 250V Time delay Secondary transformer (TR60 230V-12V 60VA)

Mechanical dimension

DIMENSION X

356 mm

DIMENSION Y

145 mm

MAXIMUM HEIGHT

49 mm

FIXING HOLES DIAMETER

4,06 mm

Working parameter

PARAMETER MINIMUM VALUE MAXIMUM VALUE

WORKING TEMPERATURE +10 °C +70 °C

STORAGE TEMPERATURE -10 °C +70 °C

WORKING HUMIDITY

-

80%

STORAGE HUMIDITY

-

90%

Regulations

PE2038A is designed in compliance with the following reg ulations:

Directive:

73/23/CEE

low voltage: electromagnetic compatibility:

89/336/ CEE

General regulations:

CEI EN50081-1

electromagnetic compatibility - emissions:

electromagnetic compatibility - immunity:

CEI EN50082-1

17
