UniView IPC675LFW-AX4DUPKC-VG Handleiding (135 Pagina's)

Handleiding

6

Live View Toolbar

Item Description

Set the image display ratio in the window.

 Scale: Displays 16:9 images.

 Stretch: Displays images according to the window size (stretch images

to fit the window).

 Original: Displays images with original size.

Set the image display mode in the window.

 Single Channel: Displays live video of a single channel.

 Left/Right Split: Displays live video in left/right split mode.

 Top/Bottom Split: Displays live video in top/bottom split mode.

 Picture in Picture: Opens a floating live view window on top of the current

window.

NOTE!

This function is only available on dual-channel cameras.

: Stop/start live view of the selected channel.

: Start local recording.

: Switch streams.

Select a live video stream according to your camera.

Set image parameters.

/

Start/stop live view.

/

Turn off/on sound.

Adjust the output volume for the media player on the PC.

Range: 1 to 100.

Adjust the microphone volume on the PC during audio communication

between the PC and the camera.

Range: 1 to 100.

Frame rate/bit rate/resolution/packet loss rate.

Take a snapshot from the displayed live video.

NOTE!

See Local Parameters for the path of the saved snapshots.

/

Start/stop local recording.

NOTE!

 See Local Parameters for the path of the saved local recordings.

 VLC media player is recommended for playing local recordings of 4K

cameras.

/

Start/stop two-way audio.

/

Start/stop digital zoom. See Digital Zoom

for details.

/

Start/stop capturing. See Snapshot for details.

Full screen.

Show/hide PTZ control panel.

1

2

3

1

2

3
