(2) Adjust the position and size of the area or draw an area as needed.

 Adjust the position and size of the area.

 Point to a border of the area and drag it to the desired position.

 Point to a handle of the area and drag to resize it.

 Draw an area.

Click on the image and drag to draw a line. Repeat the action to draw more lines to form an

enclosed shape as needed. Up to 6 lines are allowed.

Set the detection rule.

Item Description

Sensitivity

Set the detection sensitivity.

The higher the sensitivity, the more likely entry behaviors will be detected, and the more likely

false alarms will occur.

Level

Select the priority of the detection rule, including High, Medium, and Low.

The camera detects the rule that is triggered first by default. If multiple rules are triggered at

the same time, the camera detects the rule with higher priority.

Detection Object

Select the object to be detected, including

Motor Vehicle

,

Non-Motor Vehicle

, and

Pedestrian

.

Filter Type

After you select a detection object, you can set a filter rule for it.

For example, if you have selected Motor Vehicle as a detection object, select Motor Vehicle

from the Filter Type drop-down list and set the Max. Size or Min. Size for it, then motor

vehicles larger than the Max. Size or smaller than the Min. Size will not be detected.

Max. Size/Min. Size

When enabled, a box appears on the image, you can point to a handle of the box and drag

to resize it. The camera filters objects larger than the Max. Size or smaller than the Min. Size.

The width and height of the maximum filter area must be greater than that of the minimum

filter area.

Set the alarm-triggered actions and arming schedule. See Alarm-triggered Actions and Arming

Schedule for details.

Click Save.

5.6.5 Leave Area Detection

Leave area detection detects objects leaving a user-specified area. The camera reports an alarm when

the detection rule is triggered.

Go to Setup > Intelligent > Smart.
