UniView IPC3638SE-ADF40K-WL-I0 Handleiding (135 Pagina's)

Handleiding

123

Item Description

Server IP Server’s IP address.

Server Port Use the default port.

VIID Version Choose the correct version, VIID_2017 or VIID_2018.

Device ID

Make sure the entered device ID conforms to the VIID protocol, and digits 11-13 must be

119.

Username

Username configured at

VIID Management

>

VIID Device Management

>

Gateway

Authentication

on the VM.

Platform Access Code

Password configured at

VIID Management

>

VIID Device Management

>

Gateway

Authentication

on the VM.

Confirm Platform

Access Code

Enter the password again.

Configure the VIID parameters.

Item Description

Coordinate Mode Includes

Percentage Mode

,

Pixel Mode

, and

Normalized Mode

.

Connection Mode

Short Connection: This mode is implemented based on the standard HTTP protocol, and

the server decides the connection mode.

Standard: This mode is applicable only when the camera connects to a Uniview server.

Report Data Type Types of date to be reported.

 LAPI

Only Intelligent Server 2 supports LAPI. Choose LAPI and then click Save.

5.10.4 Device Information

Set device information including device name, location, mounting height, etc., which can be used in smart

FTP, OSD, etc.

Go to Setup > System > Device Info.

Complete the information as needed.

Click Save.

5.10.5 Ports & External Devices

The RS485 port is used for data transmission between the camera and external third-party devices for

PTZ control, OSD, audio collection, illumination control, etc. The serial port parameters configured on

the camera must match that of the connected external device.
