Technical data
Parameter description Parameter value
Product name Solar garden shower
Model
Plate size [mm] 145 * 180 * 8
Weight [kg]
9.35
Water pressure [bar] 3.5
Description
The product provides an alternative to conventional hot water production by using solar energy to heat water,
with adjustable temperature settings and multiple showerhead options.
Please note: The illustrations of this product can be found on the last page of the instruction manual.
The user is liable for any damage resulting from unintended use of the device.
Assembly
1. Choose a location which will receive as much as possible sunlight for your solar shower.
2. Mount the lower stand (B) with shower base to concrete slab or wood base with four bolts, washers
and nuts (K). We recommend using wrench.
3. Attach shower head (D) with gasket (G) to the extension pipe (E). Attach the extension pipe (E) with
gasket (F) to the diverter (L). Attach the diverter (L) with gasket (F) into the thread of the upper stand
(A). Adjust these parts only with your hands. Do not use a wrench. Then connect the diverter (L) an
d
the hand shower (N) by shower hose (M). Attach the holder (O) to the upper stand (A), and then put
the hand shower (N) on the holder (O).
4. Put the O-ring (C) onto the lower stand (B).
5. Mount the upper stand (A) onto the lower stand (B). Then connect the hoses.
6. Turn the locking ring clockwise to connect the two stands (A+B). Handle and shower head (D) need to
face the same direction.
7. Attach foot wash (H) with gasket (F) to the lower stand (B).
Initial Setup
1. Open the handle and turn it to position “hot”. This ensures that no air pockets are trapped in the
hoses while filling with water.
