Je bekijkt pagina 9 van 85
GB/IE/NI
9
Charging time: up to 8 hours (at 2 A)
Peak current: 400 A
Starting current: 200 A
Operating temperature for power bank: 0 °C – 60 °C
Operating temperature for LED: -20 °C – 60 °C
Temperature at which the power bank can be
charged:
0 °C – 35 °C
Voltage: 12 V
Input voltage (charging port USB-C): 5 V 2 A
Output voltage (USB port): 5 V
/1 A | 5 V /2 A
Capacity: 8400 mAh/5 V
Current draw compressor unit: max. 10 A
Maximum achievable pressure: 3.5 bar
Continuous operation: max. 7 min*
Air flow rate: 22 l/min
Engine power: 90 W
Guaranteed sound power level (L
WA
): 85 dB(A)
Measured sound power level (L
WA
): 82.9 dB(A)
Measuring uncertainty (K
WA
): 1.94 dB(A)
Sound pressure level (L
PA
): 73.3 dB(A)
Measuring uncertainty (K
PA
): 3 dB(A)
PLEASE NOTE: The noise emission values were determined in accordance with
EN ISO 3744:1995.
* Continuous operation: do not operate the integrated compressor continuously for longer than 7 minutes.
Following this, include a rest period of 15 minutes.
Changes to technical and visual aspects of the product may be made as part of future developments
without notice. Accordingly, no warranty is offered for the physical dimensions, information and
specifications in these operating instructions. The operating instructions cannot therefore be used as the
basis for asserting a legal claim.
z Safety instructions
PLEASE READ THROUGH THE OPERATING INSTRUCTIONS
CAREFULLY BEFORE USE. THESE FORM PART OF THE
PRODUCT AND MUST BE AVAILABLE AT ALL TIMES!
This section covers the basic safety instructions applicable when
working with the device.
